White corner-mount occupancy sensor with photocell and digital Cat5 connection

Acuity Sensor Switch

Acuity Sensor Switch WV PDT 16 Corner Mount Occupancy Sensor

SKU CH-13HS-AQABF

Corner-mount occupancy sensor uses PIR and microphonic detection to cover 1,200 sq ft at up to 10 ft height and switches loads up to 800 W at 120 V via digital Cat5

  • Dual PIR and microphonic sensing detects occupancy reliably
  • 1200 sq ft coverage suits large corner installations
  • Mounts up to 10 ft high for flexible placement
  • Digital Cat5 communication enables simple network integration
  • BAA compliant and cUL UL listed meets code requirements

Corner-mount occupancy sensor

The Acuity Sensor Switch WV PDT 16 is a corner-mount occupancy sensor that combines passive infrared and microphonic detection. It operates on 12 to 24V DC and communicates through a digital Cat5 cable connection. The unit provides a maximum coverage area of 1,200 sq ft when mounted at heights up to 10 ft. It carries BAA, cUL and UL listings and meets Title 24 requirements.

Suited for automated lighting control

This sensor suits installers who need a single device to manage occupancy-based lighting in corners. The dual-technology detection reduces false triggers in spaces with air movement or partitions. The digital Cat5 link simplifies wiring in networked lighting systems. Buyers who need line-voltage switching without a separate power pack or who require a ceiling-mount form factor should look at other models.

12 to 24V DC operating voltage

The sensor requires a 12 to 24V DC supply, so it cannot connect directly to 120V AC mains. A compatible low-voltage power pack or building management system must provide this power. The load rating of 800W at 120V AC applies only to the switched lighting circuit controlled through the power pack. Confirm that your control infrastructure delivers the correct DC voltage before ordering.

Highlights

  • Dual PIR and microphonic sensing detects occupancy reliably
  • 1200 sq ft coverage suits large corner installations
  • Mounts up to 10 ft high for flexible placement
  • Digital Cat5 communication enables simple network integration
  • BAA compliant and cUL UL listed meets code requirements

Specifications

BrandSENSORSWITCH

Questions about this item

Will the 12 to 24V DC occupancy sensor work with my existing 120V AC fluorescent ballasts rated at 800W?

The sensor operates on 12 to 24V DC and controls loads up to 800W at 120V AC for fluorescent or incandescent fixtures, so it can switch your existing ballasts when wired through a compatible power pack.

How can I verify the PIR and microphonic detection is covering the 1,200 sq ft area at 10 ft mounting height after installation?

Walk through the space at the 10 ft mounting height; the LED indicator on the sensor will flash when motion is detected, confirming coverage across the 1,200 sq ft zone.

Does the corner-mount sensor include the digital Cat5 cable and photocell, or must I purchase them separately?

The unit has a built-in photocell and a digital Cat5 communication interface; the Cat5 cable itself is not included and must be sourced separately for network connection.
