Telemecanique Sensors XS230AAMAL2 Inductive Proximity Sensor 30mm NO
Inductive proximity sensor detects metal at 22 mm with 24–240 V AC/DC supply and IP68/IP69K sealing
- Detects metal at 22 mm unshielded range
- Operates on 24 to 240 V AC/DC supply
- Withstands high-pressure wash-down at IP69K
- Functions from -13 °F to 185 °F ambient
- Two-wire normally-open output handles 200 mA load
Industrial Proximity Detection
The Telemecanique Sensors XS230AAMAL2 is an inductive cylindrical proximity sensor built for 30 mm mounting. It detects metal targets without physical contact at distances up to 22 mm. The unit operates on a wide 24 to 240V AC/DC supply and provides a normally open two-wire output. It suits automation and machinery monitoring tasks.
Upgrading From Limited Switches
This sensor replaces mechanical limit switches that wear out or fail in dirty environments. The jump is worth it when you need non-contact sensing with no moving parts to maintain. The 25 Hz AC or 300 Hz DC switching frequency handles rapid cycling. The unshielded design allows longer range but needs clearance from surrounding metal.
Environmental And Wiring Limits
The IP68 and IP69K ratings plus NEMA 4X protect against high-pressure washdown and immersion. The plastic case resists corrosion across a -13 to 185 degrees F operating range. The fixed 2 m cable cannot be swapped in the field. Maximum load current is 200 mA so the circuit must stay within that limit.
Highlights
- Detects metal at 22 mm unshielded range
- Operates on 24 to 240 V AC/DC supply
- Withstands high-pressure wash-down at IP69K
- Functions from -13 °F to 185 °F ambient
- Two-wire normally-open output handles 200 mA load
Specifications
| Brand | TELEMECANIQUE SENSORS |
|---|
Questions about this item
What is the unshielded 30 mm sensor's maximum detecting distance?
The unshielded sensor detects metal targets up to 22 mm away.
How do you wire the two-wire AC/DC output correctly?
Connect the two-wire cable in series with the load across the 24 to 240 V AC/DC supply; reversing the wires will prevent operation.
When should the IP68 and IP69K rated housing be inspected or replaced?
Inspect the plastic housing and 2 m cable annually; replace the sensor if the cable jacket is cracked or the housing shows impact damage.
