ZyXEL POE1230W 2.5G PoE+ 30W injector in white housing with Ethernet ports and power input

ZyXEL

ZyXEL POE1230W 2.5G PoE+ 30W injector wireless accessory

SKU CH-M7MR-F170V MPN POE1230W

A 2.5 Gigabit PoE+ injector delivering up to 30 W for WiFi 7 or WiFi 6 access points, PTZ cameras and PoE+ devices

  • TypeProduct Type: PoE+ Injector Protection Type: Overload Protec
  • SpecificationsPower Description Input Voltage: 120 V AC 230 V AC Maximum I
  • 5 Gigabit Ethernet delivers high-speed connectivity for WiFi 7 and WiFi 6 access points
  • 30 W PoE+ output powers compatible wireless APs, IP cameras and VoIP phones
  • IEEE 802.3at compliant injector works with standard PoE+ devices without configuration
  • Overload and short-circuit protection safeguards connected equipment during power anomalies
  • Universal 120 V to 230 V AC input suits international deployments

2.5G PoE+ injector for high-speed APs and cameras

The ZyXEL POE1230W is a single-port PoE+ injector built for installers and network managers who need to power WiFi 7 or WiFi 6 access points, PTZ surveillance cameras or advanced POS terminals. It delivers both data and power over one CAT-5 cable without any configuration required. The unit accepts 120 V AC or 230 V AC input at up to 1 A and 60 Hz maximum frequency.

30 W output with 2.5 Gigabit throughput headroom

The injector complies with IEEE 802.3at PoE+ and provides a maximum output power of 30 W, matching the higher budget needed by current APs and camera pan-tilt-zoom functions. Its 2.5 Gigabit Ethernet input and output ports give ample bandwidth for multi-gigabit wireless uplinks. Devices requiring more than 30 W or ports beyond a single PoE connection will need a different solution.

Overload and short-circuit protection in silent

The POE1230W includes overload protection and short-circuit protection to safeguard connected equipment during normal use. With no moving parts, it runs silently and draws a maximum input current of 1 A from the mains supply. The compact injector is designed for straightforward indoor deployment alongside compatible IEEE 802.3at powered devices.

Highlights

  • 5 Gigabit Ethernet delivers high-speed connectivity for WiFi 7 and WiFi 6 access points
  • 30 W PoE+ output powers compatible wireless APs, IP cameras and VoIP phones
  • IEEE 802.3at compliant injector works with standard PoE+ devices without configuration
  • Overload and short-circuit protection safeguards connected equipment during power anomalies
  • Universal 120 V to 230 V AC input suits international deployments

Specifications

BrandZyXEL
Part NumberPOE12-30W
TypeProduct Type:
PoE+ Injector
Protection Type:
Overload Protection
Short Circuit
SpecificationsPower Description
Input Voltage:
120 V AC
230 V AC
Maximum Input Current:
1 A
Maximum Frequency:
60 Hz
Maximum Output Power:
30 W
Interfaces/Ports
Input Ports:
1 x 2.5 Gigabit Ethernet
Output Ports:
1 x 2.5 Gigabit PoE+
Compatibility:
Zyxel Products:
WBE530
NWA130BE
WAX620D-6E
NWA220AX-6E
WAX610D
WAX510D
NWA210AX
Certifications & Standards:
IEEE 802.3u 100BASEX
IEEE 802.3ab 1000BASE-T
IEEE 802.3bz 2.5GBASE-T
Package Contents:
2.5G PoE+ Injector
Power Cord
Shipping weight0.14 kg
Package size140 × 46 × 30 mm

Questions about this item

Will the 2.5 Gigabit Ethernet input port work with my existing 1000 Mbps switch?

Yes, the 2.5 Gigabit port auto-negotiates down to 1000 Mbps so your current switch will pass data and power without configuration.

How can I confirm the injector is delivering 30 W PoE+ to my WiFi 7 access point after installation?

The access point should power on and negotiate 802.3at PoE+; check its management interface for a 30 W power-class indication and stable 2.5 Gigabit link status.

Does the box include an Ethernet cable for the 2.5 Gigabit PoE+ output or only the injector unit?

Only the injector unit is supplied; you must source a CAT-5e or better Ethernet cable separately for the 2.5 Gigabit PoE+ connection.
