Black coated steel socket weld flange, raised face, eight bolt holes

Zoro Select

Zoro Select Socket Weld Flange 2" Class 600 A105 Black Coated

SKU CH-JCF5-TX2WD

A 2-inch socket-weld flange rated Class 600 for Schedule 80 pipe, handling 1,450 psi at 72 °F and temperatures up to 780 °F

  • Rated for 450 psi at 72°F maximum operating pressure
  • Withstands up to 780°F for high-temperature steam service
  • A105 carbon steel construction with black coating for corrosion resistance
  • Class 600 flange with 8 bolt holes on 5 in bolt circle
  • Socket weld design for Schedule 80 pipe, 2 in nominal size

Zoro Select Socket Weld Flange

This Zoro Select socket weld flange suits piping systems that require a 2 inch nominal pipe size connection. It is built to Class 600 pressure ratings for demanding industrial or commercial applications. The A105 steel body provides the structural integrity needed for high-pressure service.

A105 Steel Black Coated Construction

The raised-face flange is manufactured from A105 carbon steel with a black coated finish for corrosion resistance. Its socket weld end allows direct welding to Schedule 80 pipe without additional threading. Eight bolt holes on a 5 inch bolt circle accept 5/8 inch diameter fasteners for secure mating.

Class 600 Pressure and Temperature Limits

The flange handles a maximum operating pressure of 1,450 psi at 72 degrees F and the same rating for steam service. Continuous service temperatures range from 80 degrees to 780 degrees F. These limits define the safe envelope for hydraulic, steam or process piping installations.

Highlights

  • Rated for 450 psi at 72°F maximum operating pressure
  • Withstands up to 780°F for high-temperature steam service
  • A105 carbon steel construction with black coating for corrosion resistance
  • Class 600 flange with 8 bolt holes on 5 in bolt circle
  • Socket weld design for Schedule 80 pipe, 2 in nominal size

Specifications

BrandZORO SELECT

Questions about this item

What is the maximum operating pressure for the Class 600 rating?

The flange is rated for 1,450 psi maximum operating pressure at 72 degrees Fahrenheit.

What bolt circle diameter and hole size are required for mounting?

The flange has an 8-hole pattern on a 5 inch bolt circle with 5/8 inch diameter bolt holes.

How is this flange joined to the pipe and what schedule must the pipe be?

It uses a socket weld connection and requires Schedule 80 pipe for proper fit.
