Gray graphite full-face flange gasket with stainless steel insert and eight bolt holes

Zoro Select

Zoro Select BULK-FG-968 Full Face Reinforced Graphite Flange Gasket 4" Pipe 1/16

SKU CH-5478-QAR8Y

Full-face graphite flange gasket with 316 stainless steel insert for 4-inch ANSI Class 150 piping, rated from -400 °F to 975 °F

  • Withstands extreme cold down to -400 °F
  • Handles high heat up to 975 °F
  • Reinforced with 316 stainless steel insert
  • Full-face design fits ANSI Class 150 flanges
  • 1/16 in thickness for reliable sealing

Zoro Select Graphite Flange Gasket

The Zoro Select BULK-FG-968 is a full-face gasket built for 4 inch pipe flanges rated to ANSI Class 150. It suits maintenance crews and plant engineers who need a reliable seal on piping systems handling extreme temperatures. The graphite facing with 316 stainless steel insert handles services from minus 400 degrees F up to 975 degrees F. Gray color and metal-detectable construction are not featured on this model.

Check flange specs before ordering

Verify that the mating flanges are full-face pattern with eight bolt holes matching a 3/4 inch diameter. Confirm the flange outside diameter measures 9 inches and the inside diameter is 4 1/2 inches so the gasket seats correctly. Ensure the service temperature stays within the minus 400 to 975 degree F range. No fasteners are included, so have the correct bolts and nuts ready for assembly.

Fits 4 inch Class 150 piping systems

This gasket sits between two full-face flanges and requires no separate binder material. The 1/16 inch thickness compresses to fill minor surface imperfections while the stainless insert resists blow-out under pressure. It frees the joint from spiral-wound or ring-type alternatives that need different groove profiles. The graphite facing conforms to flange faces without additional sealants in most standard installations.

Highlights

  • Withstands extreme cold down to -400 °F
  • Handles high heat up to 975 °F
  • Reinforced with 316 stainless steel insert
  • Full-face design fits ANSI Class 150 flanges
  • 1/16 in thickness for reliable sealing

Specifications

BrandZORO SELECT

Questions about this item

What comes in the box with the Zoro Select BULK-FG-968 gasket and what must be purchased separately?

The gasket is sold individually. Fasteners are not included and must be sourced separately.

How do I choose between available versions of this 4-inch full-face graphite gasket?

This listing is for the 1/16-inch thick, ANSI Class 150 version with 8 bolt holes. Other thicknesses or classes would be separate items.

What does the 975 °F maximum operating temperature mean for a real installation?

The gasket can withstand continuous service up to 975 °F and remains flexible down to -400 °F, suitable for high-temperature steam or chemical lines.
