White PVC inline swing check valve with compression and solvent weld connections

Zoeller

Zoeller 30-0100 1-1/2 in PVC Swing Check Valve

SKU CH-QYK3-KZA2X MPN 30-0100

A 1-1/2 in PVC swing check valve with neoprene seal rated for 25 psi at 130 degrees F

  • TypeDrain Components
  • Prevents backflow with inline swing mechanism
  • Handles hot water up to 130 degrees Fahrenheit
  • Rated for 25 psi at maximum temperature
  • Fits 1-1/2 inch pipe with compression and solvent weld connections
  • Installs horizontally or vertically for flexible placement

Purpose and fit

The Zoeller 30-0100 is a 1-1/2 inch PVC swing check valve designed for pump applications. It prevents back-flow in drainage lines where a simple inline valve is required.

Build and connections

The body is moulded from PVC with a neoprene seal and a PVC seat. One end uses a compression fitting and the other a solvent-weld socket, allowing the valve to be installed in either horizontal or vertical runs.

Pressure and temperature limits

The valve is rated for a maximum water pressure of 25 psi at 130 degrees F and carries no steam-pressure rating. These limits define the conditions under which the swing mechanism can maintain a reliable seal.

Highlights

  • Prevents backflow with inline swing mechanism
  • Handles hot water up to 130 degrees Fahrenheit
  • Rated for 25 psi at maximum temperature
  • Fits 1-1/2 inch pipe with compression and solvent weld connections
  • Installs horizontally or vertically for flexible placement

Specifications

TypeDrain Components
BrandZoeller
Model30-0100

Questions about this item

How does the 1-1/2 in compression x solvent weld connection affect installation?

The valve accepts a compression fitting on one side and solvent-welded PVC on the other, so you can join it to existing pipe without threading.

What clearance does the 11 in length and 8 in width require?

Allow at least 11 inches of straight run and 8 inches of side space for the swing disc to open fully in either horizontal or vertical mounting.

What step do installers often miss when solvent-welding the PVC end?

They forget to deburr and dry-fit the pipe before applying primer and cement, which can leave a leak path at the joint.
