White rectangular wall-mounted access terminal with 2.8-inch color touchscreen and RFID reader area

ZKTECO

ZKTECO SC700 2.8-inch Access Control System office equipment

SKU CH-GPDG-36AXF

Compact 2.8-inch colour touch access control terminal storing 30,000 users and 100,000 records with TCP/IP and USB data transfer

Model: Select SC700+ADMS

  • 8-inch colour touchscreen enables clear on-device interaction
  • 30,000 user and card capacity supports large organisations
  • 100,000 event records provide comprehensive audit trail
  • TCP/IP and U-Disk connectivity simplify network integration
  • Advanced access control with Wiegand in/out secures doors

Access control for up to 30,000 users

The ZKTECO SC700 is a networked access control and time attendance terminal designed for offices that manage large workforces. It stores up to 30,000 users and 30,000 cards while logging 100,000 events locally. The 2.8-inch colour touchscreen replaces the monochrome displays found on many comparable units, giving operators clear visual feedback during enrolment and daily use. TCP/IP connectivity links the device directly to the corporate LAN for real-time monitoring.

Slim wall-mount design with multi-door wiring

Measuring 104.8 by 160 by 36 mm, the unit fits standard wall boxes without protruding into corridors. Wiegand input and output ports allow it to control a door lock while simultaneously reading a second reader on the secure side, supporting anti-passback and multi-door interlocking schemes. The terminal operates reliably from 0 to 45 °C and 20 to 80 % humidity, powered by an external 12 V 3 A supply that keeps the wiring separate from the data cable.

USB backup and cloud-ready attendance

A built-in USB port lets administrators export transaction logs to a flash drive for offline auditing or upload to cloud attendance platforms without additional software licences. Multiple authentication modes — card, card plus PIN, and scheduled lock/unlock profiles — reduce the need for separate time-clock hardware. Advanced access control functions such as tamper alarm, door sensor monitoring, and duress signalling are configured on the device itself, cutting ongoing management overhead.

Highlights

  • 8-inch colour touchscreen enables clear on-device interaction
  • 30,000 user and card capacity supports large organisations
  • 100,000 event records provide comprehensive audit trail
  • TCP/IP and U-Disk connectivity simplify network integration
  • Advanced access control with Wiegand in/out secures doors

Specifications

No published specifications for this item yet.

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the SC700 use TCP/IP or Wi-Fi for network access?

The unit communicates over TCP/IP and also accepts a U-Disk for data transfer; no Wi-Fi is mentioned.

What are the exact dimensions so I can check the mounting box?

The SC700 measures 104.8 mm wide by 160 mm high by 36 mm deep.

How is the SC700 powered and what wiring mistake should I avoid?

It requires a 12 V 3 A supply; connect the lock, alarm and door-magnet wires to the correct terminals before applying power.
