Zeroplus LAP-C 16128 Logic Analyzer 16-CH 136+ protocols measurement
16-channel logic analyzer with 128 Kbit memory per channel, 200 MHz sampling and 136-plus protocol decoders
- TypeTest & Measurement Products
- Equipment TypeSignal Analysis
- Size/Dimensions95 x 125 x 25 mm
- RangeWorking Range: -6V to +6V
- Bandwidth75 MHz
- Sampling Rate200 MHz
- 16 channels capture parallel buses in one session
- 200 MHz sampling resolves fast edges with 5 ns resolution
- 128 Kbit depth per channel stores long traces for offline review
- 136 plus free protocols decode CAN I2C UART without extra licences
- 75 MHz bandwidth covers common embedded clock rates
16-Channel Logic Analyzer
The Zeroplus LAP-C 16128 is a new test and measurement instrument with 16 channels and 128Kbits memory depth per channel. It targets engineers, educators and developers who need to capture and decode digital signals in consumer electronics and similar applications.
Upgrade from Fewer Channels
Moving to 16 channels lets you monitor wider buses or multiple serial lines simultaneously, while the 136+ free protocols including CAN, I2C and UART remove the need for separate decoders. The jump is worth it when a 4-channel or 8-channel tool forces you to re-probe the same board repeatedly.
Sustained Capture Behaviour
Total memory reaches 4Mbits and compression can extend this to 32Mbits, so long acquisitions stay intact without gaps. Internal clock runs from 100Hz to 100MHz in timing mode and external clock accepts up to 100MHz in state mode, keeping sample fidelity steady during extended runs.
Highlights
- 16 channels capture parallel buses in one session
- 200 MHz sampling resolves fast edges with 5 ns resolution
- 128 Kbit depth per channel stores long traces for offline review
- 136 plus free protocols decode CAN I2C UART without extra licences
- 75 MHz bandwidth covers common embedded clock rates
Specifications
| Brand | Zeroplus Tech |
|---|---|
| Model | Zeroplus LAP-C Series Logic Analyzer |
| Part Number | FM00000166 |
| Type | Test & Measurement Products |
| Equipment Type | Signal Analysis |
| Size/Dimensions | 95 x 125 x 25 mm |
| Range | Working Range: -6V to +6V |
| Bandwidth | 75 MHz |
| Sampling Rate | 200 MHz |
| Display Type | Waveforms / Data / Packet Lists |
| Accuracy | ± 0.1 V |
| Scope Channels | Memory: 4 Mbits depth per channel |
| Application | Test & Measure |
| Approvals/Standards | FCC / CE / WEEE / RoHS / REACH |
| Color | White |
| Number of Digits | 136 |
| Mount | Yes |
| Working Temperature | 5 ? to 70 ? |
| Material | Plastic |
| Maximum Pressure | 125 psi |
| Flow Set Point | 15 |
| Flow Rate | 1.5 - 15 gpm |
| Gauge Glass Type | Standard |
| Voltage | 110V |
| Maximum Operating Temperature | 70 ? |
| Seal Material | Silicone |
| Display Size | RAM Sizes: 256K |
| Power Source | USB with DC 5V / 500mA |
| Interface | USB |
| Data Storage | Yes |
| Data Hold | Yes |
| Sensitivity | 0.3 Microns |
| Count Modes | Cumulative |
| Safety Rating | FCC / CE / WEEE / RoHS / REACH |
| Operating Frequency | 128 Hz |
| Working Distance | Working Voltage: DC 5.5V |
| Number of Functions | Data Contrast / Latch Function / Protocol Analyzer Trigger / Trigger Mark |
| Features | Fast data transfer / The patented data compression ensures that up to 255x more data can be recorded, so less memory is needed |
