Pair of black 96mm piezo tweeters with horn fronts

Yoetaun

Yoetaun TR-05 Piezo Tweeter Pair 96mm 150W 91dB 5-20KHz Black

SKU CH-VVD4-E1GH3

Pair of 96 mm piezo tweeters handling 150 W with 91 dB sensitivity across 5–20 kHz

  • ColorBlack
  • Clearer speech with 91dB sensitivity
  • Wide 5-20KHz frequency range for detailed treble
  • Handles 150W maximum power for loud output
  • Compact 96mm outer diameter fits tight spaces
  • Lightweight plastic construction enables portable use

Piezo tweeter pair for speech clarity

The Yoetaun TR-05 set contains two 96 mm piezoelectric horn tweeters designed to improve speech volume and extend sound transmission. Each unit handles up to 150 W maximum power with a sensitivity of 91 dB across a 5 to 20 KHz frequency range. The lightweight plastic construction makes the pair portable and simple to integrate into existing audio projects.

Sustained output with piezoelectric stability

Piezoelectric drivers maintain consistent performance during extended use because they lack a voice coil that can overheat under continuous load. The 150 W power rating represents the peak handling limit rather than a continuous thermal rating, so the tweeters remain stable at high output levels without compression. Their 91 dB sensitivity ensures efficient conversion of amplifier power into high-frequency detail.

Verify amplifier crossover and mounting space

Before ordering, confirm that your amplifier or crossover network provides a suitable high-pass filter starting near 5 KHz to protect the tweeters from low-frequency damage. Check that the 9.8 cm outer diameter and 8.5 cm height fit your enclosure cut-outs, noting the 6 cm inner diameter for flush mounting. The pair ships without accessories, so prepare wiring and mounting hardware separately.

Highlights

  • Clearer speech with 91dB sensitivity
  • Wide 5-20KHz frequency range for detailed treble
  • Handles 150W maximum power for loud output
  • Compact 96mm outer diameter fits tight spaces
  • Lightweight plastic construction enables portable use

Specifications

ColorBlack

Questions about this item

Does the 91 dB sensitivity of the TR-05 tweeters mean they run hot or draw a lot of power during all-day use?

The 91 dB sensitivity indicates efficient output; piezo tweeters draw minimal current and generate negligible heat even at the 150 W maximum power rating.

What amplifier connections or crossover components do I need to drive these 5-20 kHz piezo tweeters?

You need an amplifier with speaker-level outputs and a suitable high-pass crossover network to limit frequencies below 5 kHz; the tweeters connect via bare wire terminals.

Will the 96 mm TR-05 pair integrate with my older 8-ohm mid-bass drivers without impedance mismatch?

Piezo tweeters present a capacitive load rather than a fixed impedance, so they can parallel with 8-ohm drivers without changing the nominal load seen by the amplifier.
