YINGHUA
YINGHUA Z30 Infrared Touch Exit Button 90.5*86*30mm
An infrared touch exit button with NO/NC/COM contacts, IP55 rating, stainless steel plate and 500000-cycle mechanical life for access control systems
- TypeChain Guard
- MaterialMetal
- FunctionEntrance
- Infrared touch operation keeps surfaces hygienic
- IP55 rating protects against dust and water ingress
- Stainless steel 304 panel resists corrosion and wear
- Mechanical life tested to 500000 cycles
- NO NC COM contacts suit various access control systems
Z30 Infrared Exit Button for Access Control
The YINGHUA Z30 is an infrared touch exit button designed for door access control systems. It provides a contact-free way to release electric locks in offices, flats or commercial premises. The unit suits installers who need a hygienic, hands-free opener for controlled entry points. Buyers who want a mechanical push-button or a keypad entry device should look elsewhere.
NO NC COM Contacts at DC 12-36 V 3 A
The single specification that decides compatibility is the output contact arrangement: normally open, normally closed and common terminals rated for DC 12-36 V at 3 A. Your access controller must accept dry-contact signals within that voltage and current range. Systems requiring a different contact logic or a higher switching current will not work with this button.
Surface Mount with IP55 Stainless Plate
The button measures 90.5 by 86 by 30 mm and weighs 125 g, mounting directly onto a wall or door frame with a SUS 304 stainless-steel faceplate rated IP55. Wiring uses three screw terminals for NO, NC and COM; the infrared sensor needs a clear line of sight, so recessing the unit behind thick glass or metal mesh will cause false triggers. Mechanical life is tested to 500000 cycles.
Highlights
- Infrared touch operation keeps surfaces hygienic
- IP55 rating protects against dust and water ingress
- Stainless steel 304 panel resists corrosion and wear
- Mechanical life tested to 500000 cycles
- NO NC COM contacts suit various access control systems
Specifications
| Type | Chain Guard |
|---|---|
| Material | Metal |
| Function | Entrance |
Questions about this item
How does the 3 A current rating affect the electric lock it drives?
The switch can carry up to 3 A at 12–36 V DC, so it will operate most standard fail-safe or fail-secure locks directly without an extra relay.
What does the IP55 rating mean for outdoor mounting?
IP55 protects the infrared sensor and stainless-steel plate against low-pressure water jets and dust, making it suitable for sheltered exterior doorways.
Will the 90.5 × 86 × 30 mm body fit a standard UK single-gang back box?
The panel is larger than a standard 86 × 86 mm single-gang aperture, so it requires a surface-mounted box or a double-gang cut-out.
