Green E-ATX server motherboard with eight DDR4 slots, multiple PCIe x16 slots, SATA ports, dual M.2 sockets and included baffle

YINGHUA

YINGHUA X99 ALEO Mining Server Motherboard + Baffle + Switch + SATA Cable

SKU CH-FWMS-Z7R2E

E-ATX server motherboard with LGA2011 V3/V4 socket, eight DDR4 slots supporting up to 256 GB, dual M.2 NVME, eight SATA 3.0 ports and five PCIe x16 slots for GPU mining

  • CPU TypeIntel Atom
  • Supports up to five graphics cards via PCIe x16 slots
  • Eight DDR4 slots accept up to 256 GB memory
  • Dual M.2 slots support NVME and SATA drives
  • Eight SATA 3.0 ports provide extensive storage connectivity
  • Two Intel Gigabit LAN ports for reliable network throughput

X99 ALEO Mining Motherboard

The YINGHUA X99 ALEO motherboard targets mining operators who need a single board to host five graphics cards. It uses the X99 chipset with an LGA2011 V3/V4 socket and ships with a baffle, switch cable and SATA cable included. The board provides eight DDR4 slots running in four-channel mode at 2133 or 2400 MHz. It is built for density rather than general-purpose server work.

Sustained-load behaviour

All solid-state capacitors are used across the board to maintain stability during continuous 24/7 mining loads. The eight SATA 3.0 ports and dual M.2 slots supporting NVME give ample high-speed storage bandwidth for plotting or caching. Rear I/O includes dual network ports, USB 3.0 and USB 2.0 for monitoring, while front headers add further USB 3.0, audio, COM232 and fan connections. Expansion covers two PCIe x1 slots plus the five GPU slots.

Maximum memory capacity

The four-channel DDR4 design accepts up to 32 GB per module for a total ceiling of 256 GB using standard desktop or ECC memory. Buyers needing more than 256 GB of system memory must choose a different platform. The board does not support registered DIMMs beyond that limit, so capacity planning stops at the stated maximum.

Highlights

  • Supports up to five graphics cards via PCIe x16 slots
  • Eight DDR4 slots accept up to 256 GB memory
  • Dual M.2 slots support NVME and SATA drives
  • Eight SATA 3.0 ports provide extensive storage connectivity
  • Two Intel Gigabit LAN ports for reliable network throughput

Specifications

CPU TypeIntel Atom

Questions about this item

How much power and heat does the X99 ALEO motherboard generate when running five GPUs continuously?

The board itself uses all solid-state capacitors for stable delivery, but total power draw and heat depend on the specific LGA2011 V3/V4 processors and GPUs installed.

Which LGA2011 V3/V4 processors and DDR4 memory modules must I already own for this motherboard to function?

It accepts dual Intel LGA2011 V3/V4 CPUs and eight DDR4 slots supporting 2133/2400 MHz up to 256 GB using 32 GB modules.

Will my existing SATA 3.0 drives and M.2 NVME SSDs work with the eight SATA ports and two M.2 slots on this board?

Yes, the board provides eight SATA 3.0 ports and two M.2 interfaces that support NVME mode for current storage devices.
