Green rectangular server motherboard with silver CPU socket, black memory slots, and multiple expansion slots

YINGHUA

YINGHUA X99 8MD3 server motherboard LGA2011-3 DDR3

SKU CH-4MAB-FF43H

ATX server board with LGA2011-3 socket supporting Xeon E5 v3 CPUs, DDR3 ECC memory up to 64 GB, NVMe M.2 and USB 3.0

  • CPU TypeIntel Atom
  • Supports Xeon E5 v3 CPUs via LGA2011-3 socket
  • Dual-channel DDR3 memory up to 32 GB per module
  • M.2 slot for NVME solid-state storage
  • Six SATA 3.0 ports for high-speed drives
  • Six USB 3.0 and six USB 2.0 connections

YINGHUA X99 8MD3 LGA2011-3 server board

The YINGHUA X99 8MD3 is a micro-ATX server motherboard built on the X99 chipset for Intel Xeon E5 v3 processors in the LGA2011-3 socket. It targets administrators and builders who need a compact, single-socket platform with DDR3 memory and NVMe storage support.

Suits single-socket Xeon E5 v3 builds with DDR3

This board fits users moving to a single-socket Xeon E5 v3 configuration that uses registered or non-ECC DDR3 up to 64 GB across two channels. It does not suit workloads requiring more than two memory slots, more than one full-length PCIe 3.0 x16 slot, or processors outside the listed 2629V3, 2649V3, 2669V3, 2673V3, 2676V3, 2678V3 or 2696V3 models.

CPU support limited to seven specific Xeon E5 v3

The manufacturer states the 8MD3 only supports the seven Xeon E5 v3 parts listed above; other LGA2011-3 CPUs are not supported or remain untested. Verify the exact processor model before purchase to avoid compatibility issues.

Highlights

  • Supports Xeon E5 v3 CPUs via LGA2011-3 socket
  • Dual-channel DDR3 memory up to 32 GB per module
  • M.2 slot for NVME solid-state storage
  • Six SATA 3.0 ports for high-speed drives
  • Six USB 3.0 and six USB 2.0 connections

Specifications

CPU TypeIntel Atom

Questions about this item

How do I choose between the X99-8MD3 variants like T8D, T8, AD3, BD3, 8MD3 and 8M-T?

All listed codes (T8D, T8, AD3, BD3, 8MD3, 8M-T) refer to the same DDR3-based X99 board; the "T" suffix simply marks DDR3 support. Pick the exact SKU your supplier stocks — they share the LGA2011-3 socket, two DDR3 slots and identical feature set.

What does the 32 GB DDR3 peak capacity mean once the board is installed?

With two DDR3 slots running dual-channel at up to 1866 MHz, you can fit 2 × 16 GB modules for a 32 GB ceiling. Non-ECC, registered ECC or standard ECC DIMMs are all accepted, so capacity scales to whatever matched pair you install.

What does the M.2 NVMe interface cap in practice?

The M.2 slot is wired for NVMe drives and shares the X99 chipset’s PCIe 3.0 lanes, so throughput tops out at PCIe 3.0 ×4 speeds. It also works as a switchable NGFF interface if you need SATA-based M.2 instead.
