Green M-ATX server motherboard with black slots and silver heatsinks

YINGHUA

YINGHUA X79 ZD3 LGA2011 M-ATX server motherboard

SKU CH-62HS-8MV0Y

Micro-ATX server board for LGA2011 Xeon CPUs with four DDR3 channels, dual SATA3, four USB 3.0 ports and an M.2 slot switchable between NVMe and NGFF

  • CPU TypeIntel Atom
  • Supports XEON E5 processors up to 2690 for multi-threaded server workloads
  • Four-channel DDR3 memory up to 1866 MHz with REG ECC support for data integrity
  • PCIe 3.0 x16 slot plus x4 M.2 NVMe interface for high-speed storage and expansion
  • Dual SATA 3.0 and four SATA 2.0 ports provide six drive connections
  • Gigabit Ethernet and ALC887 5.1-channel audio built into 240×245 mm M-ATX board

Target platform

This M-ATX server motherboard uses the X79 chipset and an LGA2011 socket for Intel Xeon E5 processors including the 2620, 2630, 2640, 2650, 2660, 2665, 2670, 2680 and 2690 models. It is aimed at builders assembling compact rack or tower systems that need multi-core capacity in a 240 by 245 millimetre footprint. The board does not suit buyers who want integrated graphics or a consumer desktop socket.

Memory and storage headroom

Four DDR3 slots run in quad-channel mode at up to 1866 MHz and accept non-ECC, registered ECC or standard ECC modules to a peak of 32 GB per slot. Two SATA 3.0 and four SATA 2.0 ports handle traditional drives while the M.2 slot operates at PCIe 3.0 x4 and can be switched between NVMe and NGFF protocols. Builders who need more than six SATA connections or more than four memory channels will run out of native ports.

Expansion and I/O bundle

A full-size PCIe 3.0 x16 slot and a second PCIe 3.0 x4 slot provide room for a GPU plus a RAID or network card. Four USB 3.0 ports and twelve USB 2.0 headers cover peripheral and front-panel needs. Gigabit Ethernet and ALC887 5.1 audio are integrated. The seven-phase power delivery and eight-layer PCB support stable operation. Users who require multiple x16 slots or onboard Wi-Fi must add expansion cards.

Highlights

  • Supports XEON E5 processors up to 2690 for multi-threaded server workloads
  • Four-channel DDR3 memory up to 1866 MHz with REG ECC support for data integrity
  • PCIe 3.0 x16 slot plus x4 M.2 NVMe interface for high-speed storage and expansion
  • Dual SATA 3.0 and four SATA 2.0 ports provide six drive connections
  • Gigabit Ethernet and ALC887 5.1-channel audio built into 240×245 mm M-ATX board

Specifications

CPU TypeIntel Atom

Questions about this item

Will the four DDR3 slots accept my existing registered ECC modules running at 1600 MT/s?

The board supports registered ECC DDR3 at 1866, 1600, 1333 and 1066 MT/s across four channels, up to 32 GB per slot.

How can I verify the M.2 slot is running at PCIe 3.0 x4 for my NVMe drive?

Set the DIP switch to the NVMe position, then confirm in BIOS or the OS that the drive negotiates a PCIe 3.0 x4 link.

Does the box include the I/O shield and SATA cables, or must I source them separately?

The package contains the motherboard only; an I/O shield, SATA cables and any required power adapters are not included.
