Green ATX server motherboard with silver LGA 2011 socket four black DDR3 slots two M.2 slots multiple PCIe slots grey SATA ports rear

YINGHUA

YINGHUA X79 server motherboard LGA 2011 ATX

SKU CH-QSHK-8EZZK

ATX server board with LGA 2011 socket, four-channel DDR3 up to 128 GB, M.2 NVMe and SATA storage

  • CPU TypeIntel Atom
  • Supports Xeon E5 V1 and V2 processors for multi-core server performance
  • Four-channel DDR3 memory up to 128 GB for large dataset handling
  • M.2 NVMe PCIe 3.0 x4 at 32 Gbps enables fast storage throughput
  • Seven-phase power delivery with 4-layer PCB ensures stable operation under load
  • ATX form factor with 305 x 220 mm dimensions fits standard server chassis

YINGHUA X79 LGA 2011 Server Board

This ATX motherboard uses the C602 series chipset and fits Intel LGA 2011 processors. It targets builders assembling a dual-channel DDR3 workstation or entry-level server. Four memory slots accept registered ECC modules up to 128 GB total capacity.

Suits Xeon E5 V1 and V2 CPUs listed

The board supports Xeon E5 2620, 2640, 2650, 2680 and 2690 processors from both generations. Builders needing newer socket types, different core counts or memory standards not listed here should consider other platforms.

Single M.2 2280 NVMe slot at PCIe 3.0 x4

One M.2 2280 interface provides 32 Gbps bandwidth for a fast boot drive. Six SATA ports (four at 3 Gbps, two at 6 Gbps) handle additional storage. No second M.2 connector is present.

Highlights

  • Supports Xeon E5 V1 and V2 processors for multi-core server performance
  • Four-channel DDR3 memory up to 128 GB for large dataset handling
  • M.2 NVMe PCIe 3.0 x4 at 32 Gbps enables fast storage throughput
  • Seven-phase power delivery with 4-layer PCB ensures stable operation under load
  • ATX form factor with 305 x 220 mm dimensions fits standard server chassis

Specifications

CPU TypeIntel Atom

Questions about this item

How do I install the X79 motherboard into an ATX case and connect power without missing a header?

Mount the 305x220 mm board using standard ATX standoffs, then attach the 24-pin and 8-pin power connectors; the step often missed is plugging the CPU fan into the single CPU_FAN header and the two SYS_FAN headers for chassis fans.

What component will need replacement first during long-term operation?

The 7-phase power delivery and 4-layer PCB are solid, but the electrolytic capacitors around the VRM area age with heat; plan to inspect them after several years of continuous load.

Which limit appears first when the board runs sustained heavy workloads?

The four DDR3 slots max out at 128 GB and 1866 MHz, so memory capacity and bandwidth become the bottleneck before the PCIe 3.0 x16 or M.2 2280 NVMe x4 32 Gbps interfaces saturate.
