Flat green metal RFID keypad door lock with backlit touch panel

YINGHUA

YINGHUA RFID 125KHz Touch Keypad Door Lock Flat Green

SKU CH-R3CC-7EGXX

Waterproof 125 kHz RFID keypad stores 8000 cards and one password, supports card, PIN or both, and runs standalone on 12 V DC

  • TypeChain Guard
  • MaterialMetal
  • FunctionEntrance
  • Waterproof touch panel with backlight suits outdoor entrances
  • RFID 125 KHz reader reads cards from 5-10 cm
  • Stores 8000 user cards and one password locally
  • Standalone operation with full keypad programming
  • WG26/34 interface links to external exit button

Standalone RFID Access Controller

The YINGHUA 125KHz touch keypad operates as a card reader or a self-contained access controller without a computer connection. It supports entry by card, password, or combined card-and-password modes for flexible door security.

Surface Mount With Wiring Terminals

The flat green metal case is designed for wall mounting and includes terminals for power, lock relay, exit button, and Wiegand interfaces. Installers must provide a 12 V DC supply and take care to match the WG26 or WG34 wiring correctly to avoid communication faults.

8000-Card Capacity At 125 KHz

The built-in reader stores up to 8000 EM-compatible credentials and reads them from 5 to 10 cm. Buyers who need higher-frequency credentials or larger user databases should look elsewhere.

Highlights

  • Waterproof touch panel with backlight suits outdoor entrances
  • RFID 125 KHz reader reads cards from 5-10 cm
  • Stores 8000 user cards and one password locally
  • Standalone operation with full keypad programming
  • WG26/34 interface links to external exit button

Specifications

TypeChain Guard
MaterialMetal
FunctionEntrance

Questions about this item

How do I confirm the 125KHz RFID reader is working after wiring the DC12V supply?

Present an EM card within 5-10CM; the backlight keypad should respond and the 12VDC 2A relay will click to release the lock.

Which accessories are included and which must be sourced separately for a complete install?

The unit ships with the metal-case keypad and built-in RFID reader; you must supply a DC12V power source, an electric lock or strike, and an optional exit button.

Should I choose the WG26 or WG34 interface version for my existing controller?

This model provides both WG26 and WG34 input and output, so it will integrate with either protocol without a separate version choice.
