Rectangular metal touch exit button with blue backlight, 86x86x25mm

YINGHUA

YINGHUA Infrared Touch Exit Button Blue Backlight Door Lock

SKU CH-8BXE-V7MBZ

Infrared touch exit button with blue backlight for access-controlled doors, triggering release on contact and switching to red when activated

  • TypeChain Guard
  • MaterialMetal
  • FunctionEntrance
  • Infrared touch release opens doors without physical contact
  • Blue standby backlight turns red on activation for clear status
  • 3 A at 12 V DC switching with NO/NC/COM contacts fits access controllers
  • 86 × 86 × 25 mm metal housing mounts in standard gate frames
  • Operates from -20 °C to +50 °C at up to 95 % relative humidity

Infrared Touch Exit Button

The YINGHUA infrared touch exit button provides contactless door release for access control systems. A blue backlight aids visibility in low light and changes colour to indicate activation status. It suits commercial or residential entry points requiring a durable, touch-free switch.

Power and switching capacity

The unit operates on a 12 V DC supply and switches up to 3 A through normally open, normally closed and common contacts. It is rated for five hundred thousand cycle tests and functions between -20 °C and +50 °C at up to 95 % relative humidity. Continuous loads beyond the rated current or voltage are not supported.

Build, mounting and wiring

A metal body with organic glass touch surface measures 86 mm by 86 mm by 25 mm and weighs 0.105 kg. Standard screw fixing suits common gate frames. The package includes wiring instructions and two screws. No wireless or network interface is present.

Highlights

  • Infrared touch release opens doors without physical contact
  • Blue standby backlight turns red on activation for clear status
  • 3 A at 12 V DC switching with NO/NC/COM contacts fits access controllers
  • 86 × 86 × 25 mm metal housing mounts in standard gate frames
  • Operates from -20 °C to +50 °C at up to 95 % relative humidity

Specifications

TypeChain Guard
MaterialMetal
FunctionEntrance

Questions about this item

Will the 86 mm square footprint fit the same cut-out as my old mechanical push-button?

The unit measures 86 mm by 86 mm by 25 mm deep, so it matches a standard 86 mm back-box opening used by many access-control faceplates.

How do I confirm the infrared sensor is detecting touches after I wire it?

On power-up the ring glows blue; when a hand triggers the sensor it turns green and the relay clicks, showing the NO/NC/COM contacts have switched.

Does the package include the 12 V power supply and mounting back-box, or must I buy them separately?

The box contains the touch button, wiring guide, and two screws only; a DC 12 V source and any back-box are not included.
