Rectangular silver metal PSU with 120mm fan and modular cable sockets

YINGHUA

YINGHUA 500W server power supply 120mm fan fully modular ATX EU plug

SKU CH-ZYCB-YQM6Q

A 500 W fully modular ATX unit with a 120 mm hydraulic fan, EU plug, and SATA connectors for desktop or server builds

  • Delivers stable 500W rated power for demanding builds
  • Fully modular cabling keeps the case tidy and airflow clear
  • 120mm hydraulic-bearing fan moves high airflow at low noise
  • Multi-rail protections guard against over-voltage, over-current, over-load and short-circuits
  • EU plug with AC 180-264V input suits European mains directly

500 W modular server supply

This YINGHUA unit delivers a rated 500 W through a fully modular ATX design, making cable management simpler for desktop builders and technicians upgrading older workstations. The EU mains plug and 180-264 V input suit standard European sockets, while the hydraulic-bearing 120 mm fan keeps noise low during typical office or light gaming loads.

Build quality and daily connectivity

A metal chassis houses the single 24-pin motherboard connector, one 4+4-pin CPU plug, two 6+2-pin GPU leads, five SATA power ports and three large IDE fan headers. The modular sockets let you attach only the cables required, reducing clutter inside compact cases and improving airflow around the 12 cm fan intake.

Upgrade path and limits

The supply replaces non-modular or lower-wattage ATX units in systems drawing up to 396 W on the 12 V rail and 40 W on the 3.3 V rail. It is not suited for builds needing more than two PCIe power connectors, additional EPS cables or redundant server features such as hot-swap capability.

Highlights

  • Delivers stable 500W rated power for demanding builds
  • Fully modular cabling keeps the case tidy and airflow clear
  • 120mm hydraulic-bearing fan moves high airflow at low noise
  • Multi-rail protections guard against over-voltage, over-current, over-load and short-circuits
  • EU plug with AC 180-264V input suits European mains directly

Specifications

No published specifications for this item yet.

Questions about this item

Does the ATX12V design limit the 12 V rail to 396 W?

The 12 V rail is rated at 33 A, which equals 396 W, so the full 500 W rating is shared across all rails.

What clearance does the 15 cm long unit with a 120 mm fan need inside a chassis?

Allow at least 15 cm depth plus space behind the rear panel for the modular cable plugs and fan exhaust.

How do I connect the CPU power correctly with the 4+4 pin cable?

Plug the 8-pin EPS connector into the motherboard socket; if the board only has a 4-pin socket, split the cable and insert the 4-pin half, leaving the other half unused.
