Compact black box with HDMI, USB and RJ45 ports, EU power adapter included

YINGHUA

YINGHUA 150M IP HDMI KVM Extender (Only 1 RX) EU Plug

SKU CH-E5D6-2JBVP

Extends HDMI and USB keyboard and mouse signals up to 150 m over a single CAT6 cable at 1080P 60 Hz

  • TypeHDMI
  • Extends HDMI and USB up to 150 m over a single CAT6 cable
  • Delivers 1080p 60 Hz video with HDMI 1.3 and HDCP 1.2 compliance
  • Transmits keyboard and mouse control via TCP/IP network infrastructure
  • Plug-and-play setup with automatic source and display matching
  • Compact 95×70×26 mm units powered by included 5 V 2 A adapters

150 m HDMI KVM extender for remote operation

This KVM extender transmits HDMI video, audio and USB keyboard and mouse signals up to 150 metres over a single CAT6 cable. It supports 1920×1080 resolution at 60 Hz and complies with HDMI 1.3 and HDCP 1.2 standards. The kit includes a transmitter, a receiver, a mini USB cable and two 5 V 2 A power adapters. Installation is plug and play with automatic source and display matching.

Sustained transmission stability over long cable

The built-in automatic adjustment system keeps the image smooth, clear and stable during continuous operation. TCP/IP support allows the extender to traverse a standard network switch without signal degradation. HDCP 1.2 compliance maintains protected content playback over the full 150 metre distance. The compact 95×70×26 mm units run from the supplied power adapters without active cooling.

Single receiver option excludes the transmitter

This listing supplies only the receiver unit and its accessories; the transmitter is not included. Buyers who need a complete point-to-point link must purchase the transmitter separately. The receiver connects to a display and USB keyboard and mouse, then links back to a transmitter over CAT6. Without the matching transmitter the extender cannot function.

Highlights

  • Extends HDMI and USB up to 150 m over a single CAT6 cable
  • Delivers 1080p 60 Hz video with HDMI 1.3 and HDCP 1.2 compliance
  • Transmits keyboard and mouse control via TCP/IP network infrastructure
  • Plug-and-play setup with automatic source and display matching
  • Compact 95×70×26 mm units powered by included 5 V 2 A adapters

Specifications

TypeHDMI

Questions about this item

How much power does the 5V 2A adapter draw when the extender runs all day?

Each unit ships with a 5V 2A power adapter, so maximum draw is 10 watts per side under full load.

Which cables and network gear must I already have to connect the transmitter and receiver?

You need a single UTP or STP Cat5e or Cat6 patch cable up to 150m and an Ethernet switch that passes TCP/IP traffic.

Will the USB keyboard and mouse ports work with my older PS/2 peripherals through an adapter?

The extender provides standard USB HID ports for keyboard and mouse; PS/2 devices require a separate active USB-to-PS/2 converter.
