Green PCB adapter card with gold PCIe x1 edge connector and M.2 M-key slot

YEPLOOK

YEPLOOK PCIe x1 M.2 M-Key NVMe Adapter Card

SKU CH-5PTS-CVKMW

Adds an M.2 M-key NVMe SSD to a desktop PCIe x1 slot, supporting 2230, 2242, 2260 and 2280 lengths at PCIe 3.0 x1 speed

  • TypeController Card
  • Adds NVMe storage via a PCIe x1 slot
  • Supports 2230, 2242, 2260 and 2280 M-key SSDs
  • Dual solid capacitors deliver stable external power
  • Removable copper standoffs fit multiple drive lengths
  • Gold-plated connector resists wear and improves conductivity

PCIe x1 NVMe adapter for desktops

This adapter lets you install an M.2 M-key NVMe SSD into any PCIe x1, x4, x8 or x16 slot on a desktop motherboard. It targets users who need extra NVMe storage but lack a native M.2 slot. The card operates at PCIe 3.0 x1 speeds, so throughput is limited to a single lane. No drivers are required and it works with all major operating systems.

Gold-plated connector

The card uses a gold-plated PCIe interface for better conductivity and wear resistance. Two imported solid capacitors provide stable external power delivery to the SSD. Copper mounting studs are removable, allowing the board to accept 2230, 2242, 2260 and 2280 form-factor drives. Only M-key NVMe SSDs are supported; M.2 SATA B-key drives will not function in this adapter.

Adds NVMe storage where no M.2 slot exists

This card upgrades a system that has free PCIe expansion slots but no M.2 connector for NVMe drives. It is not suited for users who need full x4 NVMe bandwidth or who want to boot from the drive on older BIOSes without NVMe boot support. Builders requiring multiple high-speed drives should consider a platform with native M.2 lanes instead.

Highlights

  • Adds NVMe storage via a PCIe x1 slot
  • Supports 2230, 2242, 2260 and 2280 M-key SSDs
  • Dual solid capacitors deliver stable external power
  • Removable copper standoffs fit multiple drive lengths
  • Gold-plated connector resists wear and improves conductivity

Specifications

TypeController Card

Questions about this item

Does the PCIe 3.0 x1 interface cap the NVMe SSD to x1 speeds?

Yes, the card runs at PCIe 3.0 x1 so the SSD is limited to x1 bandwidth even in wider slots.

What SSD lengths and mounting hardware does the card accept?

It fits 2230, 2242, 2260 and 2280 M-key NVMe drives and uses removable copper standoffs for mounting.

How is the card installed and what step is often missed?

Insert the card into any PCIe x1 or larger slot, attach the SSD with the copper standoffs, and connect external power to the onboard capacitors.
