Black side-view camera with 12 IR LEDs and 120° wide angle

YanTech

YanTech Side View Roof Ceiling Mount Onboard Camera System 700TVL 120° 12 IR

SKU CH-2HCC-XX8JX

A weatherproof side-view camera with a 120° lens, 700 TVL resolution and 12 infrared LEDs for 45-foot night vision

  • ColorBlack
  • TypeRear View Camera
  • 700 TV lines resolution delivers sharp detail for safe manoeuvring
  • 120° wide-angle view covers blind spots on large vehicles
  • 12 infrared LEDs give 45 ft night vision at 0 lux
  • IP67 rating resists dust and water without extra housing
  • Adjustable mount rotates ±30° for flexible side or roof placement

CCD Side-View Camera for Vehicles

The YanTech onboard camera uses a 1/3" Sony CCD sensor to deliver 700 TV lines at 976 x 582 effective pixels. It mounts on the roof, ceiling or side of a vehicle and provides a 120 degree viewing angle that can be rotated between -30 and +30 degrees. Twelve infrared LEDs activate automatically in darkness and illuminate up to 45 feet. The IP67 rated housing is waterproof and vandal resistant without extra enclosures.

Suits rear and side visibility needs

Drivers who need a wide field of view when reversing trailers or large vehicles will benefit from the adjustable angle and night vision range. The standard RCA output connects directly to most monitors without adapters. Buyers who require a forward facing dashboard camera or a wireless transmission system should consider a different product type.

700 TV line resolution decides fit

The 700 TV line specification determines the level of detail the camera can capture for parking and manoeuvring. If your display or recording device cannot resolve this line count you will not see the full capability of the sensor. Verify that your monitor supports the resolution before purchasing.

Highlights

  • 700 TV lines resolution delivers sharp detail for safe manoeuvring
  • 120° wide-angle view covers blind spots on large vehicles
  • 12 infrared LEDs give 45 ft night vision at 0 lux
  • IP67 rating resists dust and water without extra housing
  • Adjustable mount rotates ±30° for flexible side or roof placement

Specifications

ColorBlack
TypeRear View Camera

Questions about this item

How do I choose between the side-view and roof-ceiling mounting options for this 700TVL camera?

The same unit can be mounted on the rear or either side of the vehicle, and the view angle adjusts from -30° to +30° in any direction so you can aim it for side or rear coverage.

What does the 700 TV Lines resolution deliver on a real monitor?

The 1/3" Sony CCD produces 976 × 582 effective pixels, giving a sharp analogue picture that resolves fine detail such as licence plates at typical reversing distances.

What does the standard RCA connector limit in practice?

The RCA output carries composite video only, so the maximum usable resolution is the camera's native 700 TV Lines and the signal cannot exceed standard-definition bandwidth.
