Silver rectangular rack unit with front panel indicators and rear connectivity ports

Yamaha

Yamaha RM-CR Audio Processor for ADECIA Conference Systems

SKU CH-V23M-T63G9

Central audio processor for ADECIA systems with Dante networking, auto-tuning and auto-mixing, plus USB, VoIP, analog and Bluetooth I/O

  • TypeAudio Processor
  • SpecificationOperating Temperature: 32° to 104°F (0° to 40°C) Operating H
  • Power SupplyPoE+(IEEE 802.3at, LLDP), DC 48V
  • Power Consumption15.0W
  • FeatureYamaha Unified Communications RM-CR is the audio signal proc
  • Dimension8.46" x 10.23" x 1.730"
  • Audio processor built for ADECIA conferencing systems
  • Dante network audio connects all devices with one cable
  • Auto Tuning measures the room and applies optimal sound settings
  • Auto Mixer balances every connected microphone automatically
  • USB, VoIP, analog and Bluetooth I/O for flexible integration

Signal Processor for ADECIA

The Yamaha RM-CR is the central audio signal processor for ADECIA conferencing systems. It handles routing, mixing and room optimisation for connected microphones, speakers and network devices. Dante network audio support lets compatible equipment link over a single Ethernet cable. Automatic device discovery configures audio paths without manual patching.

Integrators Building Certified ADECIA Rooms

This processor suits installers who need a Dante-based core that auto-tunes room acoustics and auto-mixes multiple microphones. It connects up to two RM-CG ceiling microphones and two VXL1B-16P line-array speakers. Certified operation with Barco ClickShare Conference, Cisco, Microsoft Teams and Zoom Rooms simplifies deployment. Buyers who need more microphone or speaker channels, or who require analogue-only infrastructure, should look at other solutions.

PoE+ Power and 15 W Draw

The unit is powered entirely through a PoE+ (IEEE 802.3at) network port with LLDP negotiation, or from an external 48 V DC supply. Maximum power consumption is 15.0 W. Operating temperature range is 0 °C to 40 °C with 30 % to 90 % non-condensing humidity. These figures determine whether the site switch budget and rack environment can support the processor.

Highlights

  • Audio processor built for ADECIA conferencing systems
  • Dante network audio connects all devices with one cable
  • Auto Tuning measures the room and applies optimal sound settings
  • Auto Mixer balances every connected microphone automatically
  • USB, VoIP, analog and Bluetooth I/O for flexible integration

Specifications

BrandYamaha
ModelRM-CR
TypeAudio Processor
SpecificationOperating Temperature: 32° to 104°F (0° to 40°C)
Operating Humidity: 30 to 90% (non-condensing)
Storage Temperature: -4° to 140°F (-20° to 60°C)
Storage Humidity: 20 to 90% (non-condensing)
Indicator: Power Indicator, Status Indicator, Bluetooth Indicator, Network Port Indicator x3
Network
Ether1: Dante Audio/Dante Control, Remote Control, WebUI, PoE+
Ether2/Ether3: Corporate Network, Remote Control, SIP, WebUI
USB Network (Front): USB2.0, Network Class, WebUI, Fixed IP
Cable Requirements: Ether1/2/3 : Cate 5e or higher (STP Recommended) USB Network : USB Cable (A-microB type)
Audio
Power SupplyPoE+(IEEE 802.3at, LLDP), DC 48V
Power Consumption15.0W
FeatureYamaha Unified Communications RM-CR is the audio signal processor at the heart of the RM series. Standard network audio support for "Dante" all compatible devices can be connected with single network cable. Up to 2 RM-CG and 2 VXL1B-16P can be connected via PoE switch SWR2311P-10G. It can automatically recognize connected devices on the same network for audio routing and is equipped with the Auto Tuning functions that automatically measure and provide the optimum sound settings for the environment as well as Auto Mixer functions that automatically mix the audio of all connected micro
Dimension8.46" x 10.23" x 1.730"
Weight3.30 lbs.
Shipping weight1.59 kg
Package size305 × 254 × 76 mm

Questions about this item

What rack space and weight should I allow for the RM-CR?

The unit measures 8.46" wide, 10.23" deep and 1.730" high and weighs 3.30 lbs, so it fits a single 1U rack slot.

How is the RM-CR powered and what cabling mistake should I avoid?

Connect a single Cat5e or better cable to a PoE+ (IEEE 802.3at) switch such as the SWR2311P-10G; do not use a standard PoE injector that only delivers 15.0 W.

What firmware or accessory updates will keep the system current?

Apply ADECIA firmware V3.0 and the latest ProVisionaire Plan release to add new routing features and maintain compatibility with certified UC platforms.
