Compact DC power analyzer with green backlit LCD and red Anderson Powerpole connectors on 12 gauge wires

WUQ

WUQ Watt Meter-PP DC Inline Power Analyzer 45A 12 Gauge Powerpole

SKU CH-7Y9E-WW7P0

Inline DC power analyzer measuring eight electrical parameters up to 60 V and 100 A with pre-wired 12-gauge Powerpole connectors

  • ProtocolOther
  • TypePlug-in Module
  • Measures 8 DC parameters including peak watts and voltage sag
  • Bright green backlit LCD display with 12 gauge wire and Powerpole connectors
  • Automatic operation with no buttons required
  • Handles up to 60V and 100A peak with 45A continuous rating
  • Compact 3.3" x 1.7" x 1.0" size for portable solar and battery testing

Inline DC Power Analyser

The WUQ Watt Meter-PP is a compact inline analyser that measures eight DC electrical parameters including amps, volts, watts, amp-hours, watt-hours, peak amps, minimum volts and peak watts. It handles up to 60V and 100A with a continuous rating of 45A. A bright green backlit LCD cycles readings automatically without any buttons. The unit ships with 12 gauge leads and pre-installed Anderson Powerpole connectors.

Portable Solar and Battery Testing

Technicians and hobbyists monitoring solar panel output or battery discharge will appreciate the automatic operation and clear parameter labels on the display. Builders needing AC measurement, data logging via USB or wireless connectivity should look elsewhere as this model provides only local DC readouts. The fixed 12 gauge wiring also limits use in very high-current installations beyond the rated capacity.

Capacity and Measurement Limits

The analyser comfortably handles continuous loads up to 45A and peaks to 100A at voltages up to 60V, making it suitable for most portable solar arrays and deep-cycle battery banks. Energy counters accumulate amp-hours and watt-hours from the load side until the meter is power-cycled. Its compact 3.3" x 1.7" x 1.0" footprint fits tight wiring looms, but the single-range design offers no higher-voltage or higher-current headroom for large off-grid systems.

Highlights

  • Measures 8 DC parameters including peak watts and voltage sag
  • Bright green backlit LCD display with 12 gauge wire and Powerpole connectors
  • Automatic operation with no buttons required
  • Handles up to 60V and 100A peak with 45A continuous rating
  • Compact 3.3" x 1.7" x 1.0" size for portable solar and battery testing

Specifications

ProtocolOther
TypePlug-in Module

Questions about this item

Does the meter need its own power source or does it draw power from the circuit it is measuring?

It draws operating power directly from the DC circuit passing through the Anderson Powerpole connectors, so no separate supply is required.

Will the 45 A continuous rating and Powerpole connectors work with my existing 12 AWG wiring and 60 V solar setup?

Yes, the unit is built with 12 gauge leads and Anderson Powerpole connectors rated for 45 A continuous and up to 60 V, matching typical 12 AWG solar or battery circuits.

How can I confirm the analyser is logging data correctly once I connect it?

The green backlit LCD cycles through Amps, Volts, Watts, Amp-hours, Watt-hours, Peak Amps, Minimum Volts and Peak Watts every second, with unit labels (Ah, Wh, Ap, Vm, Wp) shown in the lower left corner.
