WRIARICH PQ006 USB4 40Gbps 240W USB C cable 1.5ft
USB4 cable delivers 40Gbps data, 240W charging and 8K@60Hz video in 1.5ft length
- Connector TypeUSB C to USB C
- ColorBlack
- Thunderbolt 3Yes
- Terminal GenderMale to Male
- Apple CompatibleUSB-C port
- Specifications240W USB4 Cable USB Standard: The Latest USB4 Gen 3x2 Connec
- Charges up to 240W with PD 3.1 and QC 4.0
- Transfers data at 40Gbps over USB4 Gen 3x2
- Drives an 8K display at 60Hz or dual 4K at 60Hz
- Works with Thunderbolt 3 and Thunderbolt 4 hosts
- Reversible USB-C male connectors on a 1.5ft cable
WRIARICH PQ006 USB4 Cable
This 1.5ft USB C to USB C cable delivers up to 40Gbps data transfer and 240W power delivery. It suits professionals moving large media files and users charging high-power laptops. Thunderbolt 3 and 4 hosts are fully supported. Buyers needing longer reach for desk or dock setups should choose a different length.
Thermals, Noise and Power Draw
The cable operates passively with no fan or active cooling, so it adds zero noise to the system. It handles up to 48V at 5A through PD 3.1, 3.0 PPS and 2.0 without measurable heat during normal charging and data sessions. Power draw scales with the connected device and negotiated profile.
40Gbps USB4 Gen 3x2 Bandwidth
The single specification that decides fit is the certified 40Gbps USB4 Gen 3x2 bandwidth, enabling 8K at 60Hz or dual 4K at 60Hz video. Ports limited to 20Gbps Gen 2 will halve the available throughput. Users requiring only charging or lower video resolutions do not need this bandwidth tier.
Highlights
- Charges up to 240W with PD 3.1 and QC 4.0
- Transfers data at 40Gbps over USB4 Gen 3x2
- Drives an 8K display at 60Hz or dual 4K at 60Hz
- Works with Thunderbolt 3 and Thunderbolt 4 hosts
- Reversible USB-C male connectors on a 1.5ft cable
Specifications
| Brand | WRIARICH |
|---|---|
| Model | PQ006 |
| Connector Type | USB C to USB C |
| Color | Black |
| Thunderbolt 3 | Yes |
| Terminal Gender | Male to Male |
| Apple Compatible | USB-C port |
| Specifications | 240W USB4 Cable USB Standard: The Latest USB4 Gen 3x2 Connector Gender & Type: USB C Male to USB C Male, Bi-directional & Reversible. Power Delivery: PD 3.1/PD 3.0 PPS/PD2.0, QC4.0/3.0, and AFC, SCP, FCP, etc. Extended Power Range: Fully Supported, Backwards compatible with lower power requirements like 180W/140W/100W/60W and below. Supported Maximum Wattage: 240W, Compatible with Apple 140W USB-C EPR Charger to power MacBook Pro 16'' with a full load of 140W (Requires a 240W EPR PD 3.1 charger and device to load 240W). Supported Maximum Voltage: 48V, Voltage rating |
| Refresh Rate | 8K@60Hz |
| Features | 240W, Leading Fast Charging Tech: When our USB C to USB C cable paired with a compatible charger, it reaches the maximum power supported by the device, supporting up to 240W (48V/5A) power supply. Within the next 5 to 10 years, this USBC to USBC fast charging cable can completely meet the demands of fast charging, and could charge virtually any USB-C device from phones and accessories to gaming laptops. Support 8K UHD Display: Support ultra HD video resolution, 40Gbps bandwidth allows single 8K@60Hz outputs or dual 4K@60Hz video, 40Gbps speed cables are suitable for eGPU and dual 4K |
Questions about this item
How do I connect the cable and what is the common mistake?
Plug the USB‑C male connectors into the host and device ports; the reversible design works either way. The mistake is using a port that only supports USB 3.2 Gen 2, which limits bandwidth to 20 Gbps instead of the cable's 40 Gbps capability.
What will need replacement or care over time?
The cable itself has no serviceable parts. Inspect the USB‑C ends periodically for debris or bent pins; if the connector housing cracks or the cable sheath frays, replace the whole cable.
What limit appears first during sustained heavy use?
The 240 W (48 V / 5 A) power ceiling is reached before the 40 Gbps data ceiling, so prolonged maximum‑current charging will hit the thermal and voltage limit of the PD 3.1 negotiation first.
