Green M-ATX server motherboard with silver LGA2011 sockets and black PCIe slots

WMtec

WMtec X79 ZD3 LGA2011 M-ATX server motherboard

SKU CH-AZ47-DHC6F

M-ATX server board with LGA2011 socket, four DDR3 channels, dual PCIe slots, NVMe M.2 support and gigabit Ethernet

  • CPU TypeDual Intel Xeon
  • Supports dual Xeon processors for high multi-thread performance
  • Four-channel DDR3 memory up to 1866 MHz with REG ECC support
  • PCI-E 3.0 x16 slot plus x4 NVMe M.2 interface for fast storage
  • Six SATA ports including two SATA 3.0 for flexible drive arrays
  • Gigabit Ethernet and 5.1-channel audio built into compact M-ATX form factor

WMtec X79 ZD3 dual Xeon server board

This M-ATX motherboard uses the X79 chipset and two LGA2011 sockets to run paired Intel Xeon E5 processors. Four DDR3 channels accept registered ECC modules up to 32 GB each at speeds from 1066 to 1866 MT/s. It provides one PCI-E 3.0 16x slot, one PCI-E 3.0 4x slot, two SATA 3.0 ports, four SATA 2.0 ports, four USB 3.0 ports and twelve USB 2.0 connections plus an M.2 interface switchable between PCIe x4 NVMe and NGFF modes. Gigabit Ethernet and ALC887 5.1 audio are integrated.

Suits dual-socket Xeon builds with DDR3 ECC memory

Builders who need two physical CPUs, registered ECC DDR3 and an M.2 slot that can run NVMe or NGFF by dip-switch will find the required slots and chipset here. It is not for single-processor configurations, systems that require more than two SATA 3.0 ports, or workloads needing more than four memory channels.

Dual LGA2011 sockets with four-channel DDR3

The defining specification is the pair of LGA2011 sockets combined with four DDR3 channels supporting registered ECC up to 32 GB per module. This layout decides whether the board fits a dual-Xeon E5 server or workstation build.

Highlights

  • Supports dual Xeon processors for high multi-thread performance
  • Four-channel DDR3 memory up to 1866 MHz with REG ECC support
  • PCI-E 3.0 x16 slot plus x4 NVMe M.2 interface for fast storage
  • Six SATA ports including two SATA 3.0 for flexible drive arrays
  • Gigabit Ethernet and 5.1-channel audio built into compact M-ATX form factor

Specifications

CPU TypeDual Intel Xeon

Questions about this item

Does the board include any cables or brackets, or must I supply my own SATA and power leads?

The listing shows one motherboard only; no cables, I/O shield or mounting brackets are mentioned.

Which Xeon E5 models are confirmed for the LGA2011 socket on this ZD3 board?

Supported CPUs are the E5-2620, 2630, 2640, 2650, 2660, 2665, 2670, 2680 and 2690, both C2 and V2 steppings.

What does the PCI-E 3.0 16X slot deliver for an NVMe M.2 drive using the DIP-switch setting?

The M.2 interface runs at PCI-E 3.0 x4, giving full NVMe bandwidth through the DIP-switch selectable NGFF or NVMe mode.
