Green ATX motherboard with dual LGA 2011 sockets, four DDR3 slots, M.2 slot and rear I/O panel

WMtec

WMtec X79 LGA 2011 ATX server motherboard V 7.1M

SKU CH-FZRV-BWA0E

ATX server board with dual LGA 2011 sockets, four-channel DDR3 up to 128 GB, M.2 NVMe and six SATA ports

  • CPU TypeDual Intel Xeon
  • Supports dual Xeon E5 V1/V2 processors for parallel workloads
  • Four-channel DDR3 up to 1866 MHz with 128 GB maximum capacity
  • M.2 2280 NVMe PCIe 3.0 x4 delivers 32 Gbps storage bandwidth
  • Six SATA ports (four 3 Gbps, two 6 Gbps) for mixed drive arrays
  • ATX 305×220 mm with 7-phase power and 4-layer PCB

Dual-socket X79 board for Xeon E5 servers

This ATX motherboard accepts two Intel Xeon E5 processors in LGA 2011 sockets and runs four-channel DDR3 memory up to 128 GB. It targets builders assembling render nodes, virtualization hosts or storage servers that need registered ECC modules. The C602-class chipset provides the platform foundation for multi-threaded workloads. Buyers who want more storage bays or newer CPU generations should look elsewhere.

M.2 NVMe and mixed SATA ports expand drive options

A single M.2 2280 slot wired for PCIe 3.0 x4 adds fast NVMe boot or cache drives alongside four SATA 2.0 and two SATA 3.0 connectors. The seven-phase power delivery and four-layer PCB aim to keep dual-CPU configurations stable under load. Gigabit Ethernet and 7.1-channel audio cover basic networking and monitoring needs. Systems requiring 10 GbE or additional NVMe lanes are not addressed by this layout.

Standard ATX mounting fits common server chassis

The 305 by 220 mm board uses a 24-pin plus 8-pin power arrangement familiar to experienced integrators. One CPU fan header and two system fan headers provide basic cooling control. Rear I/O includes six USB 2.0 ports, PS/2, RJ45, optical audio and analog jacks. Front-panel pins add two USB 2.0, one USB 3.0, audio, COM, buzzer, POST card and on-board power buttons. Builders unfamiliar with dual-socket Xeon memory population rules should review the manual before assembly.

Highlights

  • Supports dual Xeon E5 V1/V2 processors for parallel workloads
  • Four-channel DDR3 up to 1866 MHz with 128 GB maximum capacity
  • M.2 2280 NVMe PCIe 3.0 x4 delivers 32 Gbps storage bandwidth
  • Six SATA ports (four 3 Gbps, two 6 Gbps) for mixed drive arrays
  • ATX 305×220 mm with 7-phase power and 4-layer PCB

Specifications

CPU TypeDual Intel Xeon

Questions about this item

Will the 7-phase power delivery need component replacement over time?

The 7-phase power delivery uses solid capacitors on a 4-layer PCB; no user-serviceable parts are listed, so no scheduled replacement is required.

Which thermal limit appears first when both CPUs run at full load continuously?

Only two system-fan headers and one CPU-fan header are provided, so VRM and chipset airflow typically becomes the bottleneck before CPU throttling.

How loud and hot does the board get when powered 24/7 with dual Xeons?

Three fan headers let you tune airflow; with adequate case cooling the VRM stays within spec and noise stays at typical server level.
