Gray powder-coated steel 45-degree wireway elbow, 6×6 inch, hinged screw-on cover

Wiegmann

Wiegmann L060645 45° 6×6 Gray Wireway Elbow

SKU CH-5HS1-VGNCS

A 45-degree wireway elbow routes 6-by-6 cable runs through corners with 16-gauge steel construction and gray powder-coated finish

  • TypeCable Management & Conduit
  • Length9.300
  • ColorGray
  • Weight2.9
  • 45-degree elbow routes cables smoothly around corners
  • 16-gauge steel construction withstands mechanical stress in commercial installs
  • Gray powder-coated finish resists corrosion in indoor environments
  • NEMA Type 1 and UL-listed for code-compliant wireway runs
  • Hinged screw-clamp cover allows quick access for cable pulls

45° Gray Wireway Elbow

The Wiegmann L060645 is a 45-degree wireway elbow designed to route cable runs in electrical installations. It connects sections of 6-inch by 6-inch wireway to change direction while maintaining enclosure integrity. The fitting is constructed from 16-gauge steel with a gray powder-coated finish for corrosion resistance. It carries NEMA Type 1, UL, and CSA certifications for safety compliance.

Installers using HS or S Series wireway

This elbow suits electricians and contractors building wireway systems that require a 45-degree turn in a 6x6 inch layout. The hinged screw-clamp cover allows straightforward access for wire pulling and maintenance. Buyers needing a different angle, a larger wireway size, or a fitting with knockouts should look at other configurations. It is not intended for outdoor or NEMA 4X environments.

NEMA Type 1 45-degree turn

The defining specification is the 45-degree bend angle for 6-inch by 6-inch wireway width and height. This determines whether the fitting matches the planned conduit path and the series compatibility required. The 16-gauge steel construction and screw-clamp cover locking style support the mechanical and access needs of the installation. Verified standards include UL file E32576 and CSA file LL66078.

Highlights

  • 45-degree elbow routes cables smoothly around corners
  • 16-gauge steel construction withstands mechanical stress in commercial installs
  • Gray powder-coated finish resists corrosion in indoor environments
  • NEMA Type 1 and UL-listed for code-compliant wireway runs
  • Hinged screw-clamp cover allows quick access for cable pulls

Specifications

BrandWiegmann
ModelL060645
TypeCable Management & Conduit
Length9.300
ColorGray
Weight2.9

Questions about this item

What series of wireway must I already have to mount this 45° elbow?

It is made for HS Series and S Series wireways with a 6 in by 6 in cross-section.

Will the powder-coated gray finish match older Wiegmann wireway sections I keep?

The gray powder coat is the standard finish on current Wiegmann wireway, so it will match existing sections of the same colour.

How can I confirm the elbow meets code after installation?

Look for the UL E32576 and CSA LL66078 markings stamped on the steel; they show the fitting meets NEMA Type 1 requirements.
