Small black rectangular USB camera module with wide lens

Weinandianzi

Weinandianzi WN-L2106.K222L 0.3MP 480P 60FPS 108° USB 2.0 Camera Module

SKU CH-YKMS-63HYW

A compact USB 2.0 camera module delivering 640×480 video at 60 fps with a 108° field of view

  • ColorBlack
  • Size13x9x9cm
  • SpecificationsUSB Camera Module 640Hx480V FF 108° 60FPS UVC-compliant, Plu
  • Compatibility1/3-inch GC0403 CMOS
  • Features0.3MP HD 480P 1/3-inch GC0403 CMOS USB Camera Module
  • Plug-and-play UVC compliance means instant setup
  • 108° field of view captures wide scenes
  • 60 fps at 640 × 480 delivers smooth motion
  • 3 MP GC0403 CMOS sensor provides colour video
  • Compact 26 mm module fits tight spaces

Compact USB camera module for embedded vision

The Weinandianzi WN-L2106.K222L is a 0.3MP camera module that delivers 640 x 480 video at 60FPS through a USB 2.0 interface. Its 108° field of view suits tight spaces in robotics, kiosks or inspection rigs. UVC compliance means it works without extra drivers on Linux, Windows and macOS. The 26 x 26 mm board fits directly into custom enclosures.

Verify USB 2.0 host and mounting clearance

Confirm the host provides a standard USB 2.0 port with enough current for the module. The fixed-focus lens with a 2.8 mm focal length and F/2.3 aperture cannot be adjusted after installation. Ensure the 108° wide angle covers the required scene without vignetting from nearby components. The 650 nm IR filter is built in, so external lighting must match visible-spectrum needs.

Small PCB with integrated lens and filter

The 1/4.0-inch GC0403 CMOS sensor with 6.25 µm pixels outputs MJPEG or YUY2 streams. A 4G+IR 650 nm lens assembly is soldered on the 26 x 26 mm board, keeping the optical path rigid. Black housing measures 13 x 9 x 9 cm overall. Plug-and-play operation reduces bring-up time for prototype and production batches alike.

Highlights

  • Plug-and-play UVC compliance means instant setup
  • 108° field of view captures wide scenes
  • 60 fps at 640 × 480 delivers smooth motion
  • 3 MP GC0403 CMOS sensor provides colour video
  • Compact 26 mm module fits tight spaces

Specifications

BrandWeinandianzi
ModelWN-L2106.K222L
ColorBlack
Size13x9x9cm
SpecificationsUSB Camera Module 640Hx480V FF 108° 60FPS UVC-compliant, Plug and Play
Compatibility1/3-inch GC0403 CMOS
Features0.3MP HD 480P 1/3-inch GC0403 CMOS USB Camera Module

Questions about this item

What comes in the box with the WN-L2106.K222L module and what extra items are needed?

The module itself is supplied; a USB 2.0 cable and mounting hardware are not included and must be sourced separately.

Should I choose the 640 × 480 version or a lower resolution for 60 fps capture?

The sensor’s maximum resolution is 640 × 480 at 60 fps, so that is the only version offering the full frame rate.

What does the 108° field of view mean when the camera is mounted inside a 26 mm square enclosure?

The wide 108° angle captures a broad scene even from the compact 26 mm module, suited for tight spaces.
