Small black rectangular camera board with a front lens and a 1.0 meter USB cable attached

Weinandianzi

Weinandianzi 8MP USB Camera Module IMX179 Autofocus 75° FOV 1m Cable

SKU CH-HC78-T0Y3W

An 8 MP autofocus USB camera module with a 1/3.2-inch IMX179 sensor, 75° field of view and built-in microphone for machine-vision or surveillance use

  • TypeOther
  • Quantity1
  • ColorBlack
  • Size13x9x9cm
  • Specifications1/3.2-inch IMX179 CMOS USB Camera Module
  • Compatibility1/3.2-inch IMX179 CMOS
  • 8 MP IMX179 sensor captures 3264 × 2448 stills for detailed images
  • Autofocus adjusts from millimetre close-ups to distance without manual tools
  • Built-in digital microphone records audio alongside video at up to 30 fps
  • UVC-compliant USB 2.0 works on Windows, Android, Linux and macOS without extra drivers
  • Compact 38 mm board with 75 ° field of view suits surveillance, 3D printer monitoring and machine vision

8 MP USB camera module for machine vision

This Weinandianzi camera module uses a 1/3.2-inch IMX179 CMOS sensor to deliver 8 MP still images at 3264 x 2448 resolution. It connects via USB2.0 and is UVC-compliant for plug-and-play operation on Windows, Android, Linux and Mac OS. The board measures 38 mm x 38 mm and includes a 1.0 metre cable, making it suited to surveillance, 3D printer monitoring and object recognition tasks.

Passive thermals with low power draw

The module draws power directly from the USB2.0 bus with no external supply required. Its electronic rolling shutter and compact PCB generate minimal heat during typical 15 fps or 30 fps capture. No active cooling or fan is present, so acoustic noise is effectively zero in normal indoor use.

Autofocus and microphone extend utility

Autofocus adjusts from millimetre-range subjects to distant objects without manual lens tools. A built-in digital microphone adds synchronised audio to video streams. Controllable parameters such as brightness, contrast, saturation, white balance and exposure are accessible through standard UVC interfaces on supported operating systems.

Highlights

  • 8 MP IMX179 sensor captures 3264 × 2448 stills for detailed images
  • Autofocus adjusts from millimetre close-ups to distance without manual tools
  • Built-in digital microphone records audio alongside video at up to 30 fps
  • UVC-compliant USB 2.0 works on Windows, Android, Linux and macOS without extra drivers
  • Compact 38 mm board with 75 ° field of view suits surveillance, 3D printer monitoring and machine vision

Specifications

BrandWeinandianzi
TypeOther
Quantity1
ColorBlack
Size13x9x9cm
Specifications1/3.2-inch IMX179 CMOS USB Camera Module
Compatibility1/3.2-inch IMX179 CMOS
Features8MP HD Auto Focus 1/3.2-inch IMX179 CMOS USB Camera Module

Questions about this item

How is the 1.0 meter USB cable connected to the 5PIN 1.25mm connector on the module?

The included 1.0 meter USB cable plugs directly into the 5PIN 1.25mm connector on the camera board; ensure the small connector is fully seated before securing the module.

Will the autofocus mechanism or digital microphone need replacement after extended use?

The autofocus lens and built-in digital microphone are solid-state components with no user-serviceable parts; no scheduled replacement is required.

At what resolution does the 15 fps frame-rate limit appear first during sustained capture?

The maximum 3264 x 2448 resolution is capped at 15 fps in MJPEG mode; higher frame rates are only available at lower resolutions such as 1080p at 30 fps.
