Wavlink
Wavlink WL-WN573HX3 wireless range extender AX3000 WiFi 6 outdoor 4x8dBi IP67 PoE
Weatherproof WiFi 6 extender with four 8 dBi antennas, PoE power and AX3000 dual-band speeds for up to 256 devices
- StandardsIEEE 802.1 ax/ac/n/g/a/b
- Wireless Data Rates2.4G 573Mbps+ 5G 2402Mbps
- WPA/WPA2OPEN,WPA2-PSK,WPA3/WPA2 MIX.
- Antenna4 x 8dBi Omnidirectional Antennas
- Operating ModeAP/Range Extender/Mesh Router/Mesh Extender mode.
- Features- Supports for dual band (2.4G 573Mbps+ 5G 2402Mbps) with th
- AX3000 dual-band WiFi 6 delivers 573Mbps on 2.4GHz and 2402Mbps on 5GHz
- Four 8dBi omnidirectional antennas extend coverage across large outdoor areas
- IP67 weatherproof enclosure with 15kV ESD and 6kV lightning protection withstands harsh conditions
- Passive PoE and 802.3AF/AT active PoE enable installation where no power outlet exists
- Mesh, AP, Repeater and Router modes plus support for up to 256 connected devices
Outdoor AX3000 Range Extender
The Wavlink WL-WN573HX3 is a WiFi 6 wireless range extender and media bridge built for permanent outdoor installation. Its IP67-rated enclosure withstands rain, snow and dust while four 8 dBi omnidirectional fiberglass antennas push coverage across yards, farms or campgrounds. The unit supports AP, repeater, mesh router and mesh extender modes for flexible network topologies.
Environmental resilience and power
Operating from -30 °C to 70 °C, the extender includes 15 kV ESD and 6 kV lightning protection for reliable service in storms. It draws power through a 54 V passive PoE injector or 802.3 af/at active PoE, so no local mains socket is required at the mounting point. The PoE converter itself must remain indoors and the Ethernet run should not exceed 100 m using CAT5e or better cable.
Sustained multi-device load
Under continuous demand the radio serves up to 256 associated clients with aggregate throughput of 3000 Mbps (573 Mbps on 2.4 GHz plus 2402 Mbps on 5 GHz). MU-MIMO and beamforming keep 128 simultaneous streams stable across the coverage area. Mesh interoperability is confirmed with WN586X3, WN572HP3 on current firmware and other WN573HX3 units for larger deployments.
Highlights
- AX3000 dual-band WiFi 6 delivers 573Mbps on 2.4GHz and 2402Mbps on 5GHz
- Four 8dBi omnidirectional antennas extend coverage across large outdoor areas
- IP67 weatherproof enclosure with 15kV ESD and 6kV lightning protection withstands harsh conditions
- Passive PoE and 802.3AF/AT active PoE enable installation where no power outlet exists
- Mesh, AP, Repeater and Router modes plus support for up to 256 connected devices
Specifications
| Brand | Wavlink |
|---|---|
| Model | 573HX3 |
| Standards | IEEE 802.1 ax/ac/n/g/a/b |
| Wireless Data Rates | 2.4G 573Mbps+ 5G 2402Mbps |
| WPA/WPA2 | OPEN,WPA2-PSK,WPA3/WPA2 MIX. |
| Antenna | 4 x 8dBi Omnidirectional Antennas |
| Operating Mode | AP/Range Extender/Mesh Router/Mesh Extender mode. |
| Features | - Supports for dual band (2.4G 573Mbps+ 5G 2402Mbps) with the aggregated speeds up to 3000Mbps. - Supports one WAN/LAN Ethernet Gigabit port. - Complies with IEEE 802.1 ax/ac/n/g/a/b standards. - Supports AP/Range Extender/Mesh Router/Mesh Extender mode. - Encryption type: OPEN,WPA2-PSK,WPA3/WPA2 MIX. - 2x8dBi 5GHz and 2x8dBi 2.4GHz detachable omni-directional external antennas provide excellent wireless performance. - Glass tube antenna for high precision, corrosion resistance. long life, strong wind resistance. - Seamless and stable WiFi Mesh makes you enioy seamless roaming throug |
| Operating Temperature | -30°C~70°C |
| Package Contents | 1 x AX3000WiFi 6 Outdoor Access Point 4 x Omni Antennas 4 x Cable Ties 1 x Ethernet Cable Connectors 1 x Quick Installation 1 x Wrench 2 x Silicone Pads Several Screws Passive PoE(Optional): 1 x 54V Power Adapter 1 x PoE Converter 1 x Ethernet Cable |
Questions about this item
How do I mount the WL-WN573HX3 outdoors and what is the step installers often miss?
Mount the unit 2 to 3 metres above ground using the supplied screws and cable ties; the step often missed is keeping the PoE converter indoors because it is not waterproof.
What maintenance will the antennas and seals need over time?
The four 8 dBi fiberglass omnidirectional antennas are built for long service life; periodically check the IP67 enclosure seals and cable glands for debris or damage after severe weather.
What is the first limit reached when many devices connect continuously?
The extender supports up to 256 associated devices, with 128 simultaneous connections on the 5 GHz band before MU-MIMO scheduling becomes the bottleneck.
