Black vertical docking station with matte finish, multiple video and data ports on front and back

Wavlink

Wavlink 69DK5 USB-C Dual 4K Docking Station

SKU CH-RXVC-M6P1F

Adds dual 4K or single 5K video, seven USB ports, gigabit Ethernet and audio over one USB-C or USB-A cable

  • ColorBlack
  • CompatibilityWindows 10, 8.1, 8, 7, XP systems, Mac OS 10.6 Donwards,-Mac
  • Ports SpecTHIS DOCK DOESN'T support Power Delivery function! ! 1 x Typ
  • FeaturesUSB3.1 Gen1 Type-C and Standard-A connectors compatible both
  • Content1 x USB-C Universal Docking Station 1 x USB 3.0 C to C Cable

Option HDMI & DP - 4K - USB-C and USB 3.0 Laptops

  • Dual 4K monitors at 60 Hz via HDMI or DisplayPort
  • Single 5K display up to 5120 × 2880 at 60 Hz on one DisplayPort
  • Seven USB ports including two Type-C with 5 V/3 A charging
  • Gigabit Ethernet plus audio and mic jack for wired networking
  • Works with USB-C and USB-A laptops on Windows and macOS

Universal USB-C Dock for Dual 4K Displays

This Wavlink 69DK5 docking station adds two 4K monitors at 60 Hz through HDMI or DisplayPort and a single 5K panel at 60 Hz over DisplayPort. It connects to laptops with USB-C or USB-A ports and works on Windows 10, 8.1, 8, 7 and XP as well as Mac OS 10.6 and later. No support exists for Linux, Unix or ARM-based Windows devices.

Driver-First Setup With No Laptop Charging

Installation requires a manual DisplayLink driver download on both Windows and Mac; Mac OS 10.13.4 through 10.13.6 only allow one extended screen and need Screen Recording permission enabled. The dock does not deliver Power Delivery, so the host laptop must use its own charger. A 20 V DC adapter is included for the dock itself.

Dual 4K 60 Hz Video Over USB Bandwidth

The built-in DisplayLink GPU drives two 3840 x 2160 displays at 60 Hz simultaneously via HDMI 2.0 and DisplayPort 1.2, or a single 5120 x 2880 panel at 60 Hz. This capability depends on the host providing sufficient USB 3.0 or 3.1 Gen 1 bandwidth rather than native GPU outputs.

Highlights

  • Dual 4K monitors at 60 Hz via HDMI or DisplayPort
  • Single 5K display up to 5120 × 2880 at 60 Hz on one DisplayPort
  • Seven USB ports including two Type-C with 5 V/3 A charging
  • Gigabit Ethernet plus audio and mic jack for wired networking
  • Works with USB-C and USB-A laptops on Windows and macOS

Specifications

BrandWavlink
Model69DK5
ColorBlack
CompatibilityWindows 10, 8.1, 8, 7, XP systems, Mac OS 10.6 Donwards,-Mac OS 10.13.4 - 10.13.6 has single extended display support with AirPlay. No support on Linux/Unix or ARM based Windows operating systems (such as Surface RT)(MacOS Big Sur please download driver: https://www.synaptics.com/products/displaylink-graphics/downloads/macos), Note: Need manual driver installation on Mac, then enable Screen Recording
Ports SpecTHIS DOCK DOESN'T support Power Delivery function! !
1 x Type-C (Connect to laptop)
2 x HDMI
2 x USB-C
2 x DisplayPort
3 x USB-A 3.0
1 x 4-Pole Phone Jack
1 x RJ45 Gigabit Ethernet
1 x DC Power Jack Port
FeaturesUSB3.1 Gen1 Type-C and Standard-A connectors compatible both Type-C and Type-A Laptop
Build in USB 3.0 GPU, Plug and Display Certified by DisplayLink
2 x DisplayPort++ (Dual Mode DisplayPort 1.2) and 2 x HDMI (Version 2.0) support resolution up to dual (4K)4096 x 2160@60Hz/(5k)5120x1440@60hz
Support resolution (5K)5120 x 2880p60 when dual dp ports are connected to the 5k monitor
Support Extend and Mirror Video Mode. 5.1 Channel surround-sound through Display Port interface
Gigabit Ethernet network RJ-45 backward 10/100 Ethernet
Audio Line-out for Earphone and Line-In Microphone Audio
Content1 x USB-C Universal Docking Station
1 x USB 3.0 C to C Cable
1 x USB 3.0 A to C Cable
1 x DC20V Certified Power Adapter
1 x User Manual

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I verify the dock is delivering dual 4K at 60 Hz after connecting my monitors?

Check your display settings on Windows or Mac to confirm each external monitor shows 3840 x 2160 at 60 Hz; the dock's integrated GPU handles the video so CPU load stays low.

Which cables and adapters are included, and what must I supply myself?

The box contains the dock, a USB 3.0 Type-C to Type-C cable, a USB 3.0 Type-A to Type-C cable, a 20 V DC power adapter and a user manual; you must provide your own HDMI or DisplayPort cables for the monitors.

Should I choose the DisplayPort or HDMI outputs for a single 5K monitor?

Use one DisplayPort output to reach 5120 x 2880 at 60 Hz; HDMI ports are limited to 4K at 60 Hz.
