White brass pressure regulator with gauge port and threaded connections

Watts

Watts 3/4 LFH560-G Pressure Regulator 10-60 psi

SKU CH-684J-WQSE2 MPN 3/4

Lead-free brass water pressure regulator adjusts from 10 to 60 psi with an included gauge and 300 psi maximum rating

  • TypeDrain Components
  • ColorWhite
  • Adjustable 10 to 60 psi range suits varied water pressure needs
  • Lead-free brass body meets IAPMO standards for safe potable water use
  • Includes pressure gauge for direct system monitoring without extra tools
  • Buna-N seals rated to 140 °F handle typical residential hot water temperatures
  • 300 psi maximum pressure rating provides durability margin above normal supply pressure

Pressure Regulator 10-60 psi

The Watts LFH560-G pressure regulator controls water pressure in residential and light commercial plumbing systems. It accepts supply pressure up to 300 psi and delivers an adjustable outlet range of 10 to 60 psi. Lead-free brass construction meets potable-water requirements.

Included Pressure Gauge

A factory-supplied pressure gauge threads into the 1/8-inch gauge port for immediate visual confirmation of outlet pressure. The gauge eliminates the need for a separate test instrument during installation and simplifies future maintenance checks.

300 psi Maximum Inlet

The regulator handles supply spikes up to 300 psi while maintaining the 10 to 60 psi adjustment band. Operating temperature is rated to 140 degrees Fahrenheit. Systems requiring pressure settings above 60 psi or temperatures exceeding 140 degrees Fahrenheit need a different valve.

Highlights

  • Adjustable 10 to 60 psi range suits varied water pressure needs
  • Lead-free brass body meets IAPMO standards for safe potable water use
  • Includes pressure gauge for direct system monitoring without extra tools
  • Buna-N seals rated to 140 °F handle typical residential hot water temperatures
  • 300 psi maximum pressure rating provides durability margin above normal supply pressure

Specifications

TypeDrain Components
ColorWhite
BrandWatts
Model3/4 LFH560-G

Questions about this item

How often will the Buna N seals need replacement?

Buna N seals typically last several years under normal water service up to 140 Degrees F; inspect annually and replace if leaks appear at the gauge port or connections.

What pressure limit is reached first during continuous flow?

The regulator maintains outlet pressure between 10 and 60 psi; sustained inlet pressure above 300 psi will exceed the body rating before the adjustment range is overrun.

Does the brass body get hot or make noise when regulating all day?

Lead-free brass runs at water temperature up to 140 Degrees F with no moving parts that generate noise; power consumption is zero because it operates hydraulically.
