Wasp Barcode
Wasp Barcode WLR8950 Bi-Color CCD barcode scanner
Handheld corded CCD scanner reads 1D barcodes up to 12 inches away with bi-color LED lighting for colored labels and survives repeated six-foot drops to concrete
- Form FactorHandheld
- ConnectivityCorded
- Scan Engine1D Long Range CCD Scanner
- Included CablesUSB Cable Included
- Interfaces SupportedUSB
- Light Source630 nm visible red LED; 525 nm visible green LED
- Scans coloured barcodes accurately with bi-color 630 nm red and 525 nm green LEDs
- Reads 1D codes from 25 mm to 300 mm distance at 15.6 mil
- 450 scans per second speed keeps checkout lines moving
- Survives multiple 6' drops to concrete with durable ABS construction
- Connects instantly via USB cable with no extra drivers needed
Handheld 1D Long-Range CCD Scanner
The Wasp WLR8950 is a corded handheld barcode scanner built for retail point-of-sale and repetitive scanning tasks. Its pistol-grip design and durable ABS construction withstand multiple 6' drops to concrete, reducing downtime in busy environments. The bi-color dual LED light source automatically switches between 630 nm red and 525 nm green to read coloured 1D barcodes at distances up to 12 inches. A 450 scans-per-second engine speeds throughput for high-volume workflows.
USB Corded Interface and Power Limits
The scanner connects through a USB interface with an included cable, drawing under 340 mA in single-colour mode and under 370 mA in bi-colour mode at 5 VDC ± 5%. Idle consumption stays below 240 mA over USB. The corded design restricts mobility to the cable length, so the device suits fixed workstations rather than roaming inventory tasks. No wireless or battery operation is supported.
3-Mil Resolution and Depth-of-Field Constraints
A 3-mil resolution defines the finest barcode element the engine can resolve, limiting use to symbols printed at or above that density. Depth of field ranges from 80 to 100 mm at 4 mil Code 39, 80 to 125 mm at 5 mil Code 39, 25 to 300 mm at 15.6 mil EAN, and 95 to 170 mm at X:10 mil Y:1 mm PDF 417. Buyers needing to scan codes smaller than 3 mil or at distances outside these bands should select a different engine.
Highlights
- Scans coloured barcodes accurately with bi-color 630 nm red and 525 nm green LEDs
- Reads 1D codes from 25 mm to 300 mm distance at 15.6 mil
- 450 scans per second speed keeps checkout lines moving
- Survives multiple 6' drops to concrete with durable ABS construction
- Connects instantly via USB cable with no extra drivers needed
Specifications
| Brand | Wasp |
|---|---|
| Model | WLR8950 |
| Part Number | 633808121662 |
| Form Factor | Handheld |
| Connectivity | Corded |
| Scan Engine | 1D Long Range CCD Scanner |
| Included Cables | USB Cable Included |
| Interfaces Supported | USB |
| Light Source | 630 nm visible red LED; 525 nm visible green LED |
| Resolution | 3 mils |
| Depth of Scan Field | 80 to 100 mm at 4 mil (Code 39); 80 to 125 mm at 5 mil (Code 39); 25 to 300 mm at 15.6 mil (EAN); 95 to 170 mm at X:10 mil, Y:1mm (PDF 417) |
| Scan Speed | 450 scan/s |
| Print Contrast Ratio (Minimum) | 30% |
| Decoding Capability | Bar Code Symbology Supported: UPC-A/UPC-E EAN-8/EAN-13 Industrial 2 of 5 Codabar Matrix 2 of 5 Code 11 Code 93 Code 32 Code 128 Standard Code 39 Full ASCII Code 39 Interleaved 2 of 5 China Postal Code MSI Plessy Code UK Plessy Code EAN/UCC 128 Telepen Code IATA Code |
| Input Voltage | 5 VDC ± 5% |
| Current | Working current consumption: <340 mA (single color mode); <370 mA (bi-color mode) Idle current consumption: <220 mA (PS2); <240 mA (USB |
| Color | Yellow/Black |
| Dimensions | 6.30" x 2.70" x 3.50" |
| Weight | 0.30 lb. |
| Features | Increase accuracy and efficiency compared to manual data entry processes Economical barcode scanner allows for a cost effective scanning solution Simple to implement and use, connect to your PC through a USB or PS2 cable Ergonomic and lightweight form factor ensures comfort Durable construction eliminates downtime due to breakage Error free scanning accurately adds data to your active document, spreadsheet, or database Read 1D, colored barcodes up to 12" away Automatic bi-color technology changes light sources between green and red for improved scanner performance Scan barcodes with |
| Drop | Withstands multiple 6' drops to concrete |
| Ruggedness | Rugged |
| Shipping weight | 0.91 kg |
| Package size | 198 × 147 × 86 mm |
Questions about this item
Which Wasp WLR8950 version should I choose for coloured barcodes?
The WLR8950 uses a bi-colour dual LED light source at 630 nm red and 525 nm green that automatically switches to read red barcodes with green light and green barcodes with red light.
What does 450 scan/s mean when I am at the till?
The scanner performs 450 scans per second, so a trigger pull captures the code almost instantly even on low-contrast labels down to 30 % print contrast ratio.
What does the USB interface cap in practice?
The USB connection supplies 5 VDC ± 5 % and draws under 370 mA in bi-colour mode, so it runs from a standard PC port without an external power supply.
