Square black metal axial fan with wire guard and lead wires

Vszerda

Vszerda UF-15AC23 BTH Axial Fan AC 230V 27/26W

SKU CH-RH61-ZMZV6

Compact 172×150×38 mm axial fan moves 177–212 CFM at 230 VAC, 50/60 Hz

  • Delivers 177 CFM airflow at 50 Hz
  • Reaches 212 CFM airflow at 60 Hz
  • Operates on standard 230 VAC mains power
  • Certified to CUL, CE, TUV and UL standards
  • Runs at 2850 rpm at 50 Hz and 3400 rpm at 60 Hz

Vszerda UF-15AC23 Axial Fan

The Vszerda UF-15AC23 is an AC axial fan rated for 230 VAC operation at 50/60 Hz. It suits equipment builders and maintenance engineers who need a compact 172x150x38 mm frame for chassis or cabinet cooling. The unit weighs 0.72 kg and carries CUL, CE, TUV and UL certifications. It is sold as a single fan without mounting hardware.

Thermals noise and power draw

At 50 Hz the fan draws 27 W and 0.18 A while delivering 177 CFM at 2850 min⁻¹ with a noise level of 54 dB. At 60 Hz power drops to 26 W and current to 0.11 A while speed rises to 3400 min⁻¹, airflow increases to 212 CFM and noise reaches 58 dB. Static pressure reaches 17 mmH₂O at 50 Hz and 19 mmH₂O at 60 Hz.

Bundled accessories and software impact

The package contains only the fan itself, so installers must supply their own mounting screws, guards and wiring connectors. No software, speed controller or thermal probe is included, meaning speed is fixed at the two line-frequency points. Buyers who need variable speed or PWM control must add external electronics.

Highlights

  • Delivers 177 CFM airflow at 50 Hz
  • Reaches 212 CFM airflow at 60 Hz
  • Operates on standard 230 VAC mains power
  • Certified to CUL, CE, TUV and UL standards
  • Runs at 2850 rpm at 50 Hz and 3400 rpm at 60 Hz

Specifications

No published specifications for this item yet.

Questions about this item

How do I mount the 172×150×38 mm frame and wire the 230 VAC supply without reversing line and neutral?

Bolt the fan through its four corner holes using M4 hardware, then connect the two supply leads to a 230 VAC 50/60 Hz circuit; the motor is not polarity-sensitive, but always isolate the mains before wiring.

Which component will need attention first during continuous 230 VAC operation?

The sleeve-bearing motor is the primary wear item; expect increased noise above 54/58 dB or reduced airflow below 177/212 CFM as the lubricant ages.

What thermal limit appears first when the fan runs at 2850/3400 min⁻¹ under sustained load?

The motor’s insulation class caps winding temperature; once internal heat pushes the windings past that limit, the 0.11/0.18 A current draw rises and the fan must be shut down to cool.
