Square black metal axial fan with wire grille and two lead wires

Vszerda

Vszerda UF-15AC23 Axial Fan AC 230V 27/26W

SKU CH-71FZ-2M30C

Compact 172 × 150 × 38 mm axial fan moves 177–212 CFM at 230 V AC with CUL, CE, TUV and UL certification

  • Delivers 177 CFM airflow at 50 Hz
  • Moves 212 CFM air volume at 60 Hz
  • Certified to CUL CE TUV UL safety standards
  • Operates on 230 VAC at 50/60 Hz
  • Compact 172x150x38 mm frame fits tight spaces

Industrial cooling fan for 230 V systems

The Vszerda UF-15AC23 is a new axial fan built for 230 VAC mains operation at 50/60 Hz. It targets installers and maintenance teams who need a certified replacement for enclosures, cabinets or machinery ventilation. The unit carries CUL, CE, TUV and UL marks.

Dual-speed airflow with 177 to 212 CFM capacity

At low speed the fan draws 26 W and delivers 177 CFM at 2850 min⁻¹ with 54 dB noise. At high speed it draws 27 W, reaches 3400 min⁻¹, moves 212 CFM and produces 58 dB. Static pressure ranges from 17 to 19 mmH₂O. The 172×150×38 mm frame and 0.72 kg weight define the mounting envelope.

Single-unit pack requires external wiring

The package contains only the fan itself. No cord, plug, grille, filter, speed controller or mounting hardware is supplied. The installer must provide a 230 VAC supply rated for at least 0.18 A, suitable over-current protection and a safe mechanical fixing method.

Highlights

  • Delivers 177 CFM airflow at 50 Hz
  • Moves 212 CFM air volume at 60 Hz
  • Certified to CUL CE TUV UL safety standards
  • Operates on 230 VAC at 50/60 Hz
  • Compact 172x150x38 mm frame fits tight spaces

Specifications

No published specifications for this item yet.

Questions about this item

Will the 172x150x38mm frame and 230 VAC supply match the cut-out and wiring of the older UF-15 unit I am replacing?

The fan measures 172 by 150 by 38 mm and runs on 230 VAC at 50/60 Hz, so it fits the same panel cut-out and connects to the same mains supply as the earlier UF-15 model.

How can I confirm the fan is running at the rated 2850/3400 min⁻¹ after installation?

Measure the current draw — it should read about 0.11 A — and listen for the specified 54/58 dB noise level; both indicate the motor is hitting its rated speed.

Does the package include mounting screws or a power cord, or must I buy them separately?

The box contains only the fan unit itself; mounting hardware and a mains lead are not included and must be sourced separately.
