Vszerda ITHOO 32-bit 33MHz Mini PCI-e to Dual PCI Expansion Card

Interface and Slots

This Vszerda ITHOO expansion card converts a single Mini PCI-e slot into two standard PCI slots. It operates on a 32-bit 33 MHz bus and includes a blue LED power indicator. The design allows both PCI slots to run simultaneously, a difference from typical single-slot adapters.

Use Case and Limits

The card suits users adding legacy PCI capture, sound or parallel-port cards to a system that only offers a Mini PCI-e connection. It draws less than 16 W and needs no external power brick, using onboard SATA and DC 5.5 connectors for supplemental power instead. Builders who require more than two PCI slots or need a different host interface such as full-size PCI-e should look elsewhere.

Power Delivery

Solid capacitor filtering on the PCI slot supply lets the board operate in high and low temperature environments. The 16 W ceiling and dual onboard power inputs give flexibility for cards with higher draw, but the total power budget remains the deciding factor for which PCI devices can be used together.
