Small black HDMI splitter box with multiple ports and LED indicators

Vszerda

Vszerda HDMI Splitter 1x2 4K 30Hz HDMI 1.4a 3D Audio

SKU CH-PN2W-M14DJ

Distributes one HDMI 1.4a source to two displays at up to 4K 30 Hz with 3D, CEC and 7.1 digital audio

  • Distributes one HDMI source to two displays simultaneously
  • Supports 4K resolution at 30 Hz refresh rate
  • Handles 3D video and CEC control signals
  • Decodes DTS-HD, Dolby-true-HD and LPCM 7.1 audio
  • Accepts DC 5 V power with LED status indication

Vszerda HDMI Splitter 1x2 4K 30Hz

The Vszerda HDMI Splitter 1x2 takes a single HDMI 1.4a source and duplicates it to two displays simultaneously. It supports 4K resolution at 30Hz, 3D content, and HDCP 1.0 through 1.3. Digital audio formats including DTS-HD, Dolby TrueHD, and LPCM 7.1 are passed through. It is suited for retail displays, control rooms, boardrooms, and training environments.

Plug-and-play setup with 5V DC power

Installation requires connecting the source to the input and two displays to the outputs, then attaching the included DC 5V power supply. The unit uses signal retiming to maintain stability. Using a power supply with higher voltage may damage the device. LEDs indicate active connections on each port. No software or driver installation is needed for operation.

4K 30Hz and 1080p 60Hz headroom

The splitter handles resolutions up to 4K at 30Hz and 1080p at 60Hz, plus 576i, 576p, 720p, and 1080i. It supports 30-bit and 36-bit deep colour. It will not pass 4K at 50Hz or 60Hz, nor does it support HDMI 2.0 features such as higher bandwidth or VRR. Buyers needing 4K 60Hz distribution or more than two outputs should consider a different device.

Highlights

  • Distributes one HDMI source to two displays simultaneously
  • Supports 4K resolution at 30 Hz refresh rate
  • Handles 3D video and CEC control signals
  • Decodes DTS-HD, Dolby-true-HD and LPCM 7.1 audio
  • Accepts DC 5 V power with LED status indication

Specifications

No published specifications for this item yet.

Questions about this item

How do I verify the splitter is working after connecting the 5 V DC power and two displays?

When the source and both displays are powered on the corresponding LED on the unit lights up, confirming an active HDMI 1.4a link at up to 4K 30 Hz with HDCP 1.0–1.3 and audio formats such as DTS-HD or LPCM 7.1.

What comes in the box and what must I supply myself?

The splitter unit itself is included; you must provide the HDMI cables for the single input and two outputs plus a 5 V DC power adapter because the device does not draw power from the HDMI ports.

Should I choose the 1×2 model or a larger 1×4 version for two screens?

For exactly two displays the 1×2 version matches the requirement; the 1×4 variant adds two extra outputs you would not use and still requires the same 5 V DC supply and HDMI 1.4a cabling.
