Compact black metal box with HDMI ports and IR sensor

Vszerda

Vszerda HD0104S 4K60Hz HDMI Video Wall Controller 2x2 180° Rotate

SKU CH-RTWJ-5FFB3

Splits one 4K HDMI signal across four displays in 2×2, 1×4 and other layouts with 180° rotation via remote

  • Interface,
  • Feature, , , ,
  • Features, , , ,
  • Package Content, , , ,
  • Package Contents, , , ,
  • Divides one 4K 60 Hz HDMI signal across four displays
  • Point-to-point mapping delivers 1920×1080 per screen in 2×2 layout
  • Seven splice modes including 1×4 at 7680×1080 60 Hz
  • 180 ° rotation per output corrects orientation without stretching
  • IR remote assigns any output to any screen instantly

4K60 Hz HDMI video wall controller

The Vszerda HD0104S splits one HDMI 4K input into four HDMI outputs for a 2x2 video wall. It accepts a 7680x1080@60 Hz signal and drives each display at 1920x1080@60 Hz. HDMI 2.0 and HDCP 2.2 compliance allow protected 4K content to pass through. An IR remote and front-panel buttons handle all switching.

Installers needing quick multi-screen layouts

The unit suits control rooms, retail signage and live-event backdrops where a single source must fill four screens without stretching. It also supports 1x4, 4x1, 1x3, 3x1, 1x2 and 2x1 splice modes with 180° rotation per output. Buyers who require more than four outputs or native 4K per screen should consider a matrix switcher instead.

18 Gbps bandwidth ceiling

The 18 Gbps link limits total pixel throughput to the resolutions listed in the specifications. Any layout demanding higher aggregate bandwidth than the supported modes will not work.

Highlights

  • Divides one 4K 60 Hz HDMI signal across four displays
  • Point-to-point mapping delivers 1920×1080 per screen in 2×2 layout
  • Seven splice modes including 1×4 at 7680×1080 60 Hz
  • 180 ° rotation per output corrects orientation without stretching
  • IR remote assigns any output to any screen instantly

Specifications

BrandVszerda
ModelHD0104S
Part NumberMT-HD0104S
Interface,
Feature, , , ,
Features, , , ,
Package Content, , , ,
Package Contents, , , ,

Questions about this item

Should I choose the 2x2 mode or the 1x4 mode for my four displays?

Use 2x2 mode when you need a 4K 60 Hz picture across four 1080p screens. Choose 1x4 mode if your source is 7680x1080 at 60 Hz and you want each screen to show a horizontal slice.

What does the 4K 60 Hz input actually deliver on each output in a 2x2 layout?

The controller splits a 4K 60 Hz signal into four 1920x1080 60 Hz outputs, giving each display a quarter of the original frame with no stretching.

How does the HDMI 2.0 18 Gbps limit affect the resolutions I can run?

The 18 Gbps bandwidth caps the input to 4K 60 Hz 4:4:4 and each output to 1080p 60 Hz, so higher refresh rates or deeper colour depths are not supported.
