Blue circuit board with 19/20-pin USB 3.0 headers and a short SATA power cable attached

Vszerda

Vszerda CY-U3-084-EF USB 3.0 19/20Pin to USB 3.1 Type E Adapter with SATA Power Cable 0.6m

SKU CH-6EYK-7GB34

Converts a motherboard USB 3.0 19/20-pin header to a USB 3.1 Type E header with a 0.6 m SATA power cable for front-panel devices

  • TypeUSB 3.0
  • Connector TypeUsb 3.0 20pin 19pin
  • Cable Length0.6
  • Length0.6
  • Connector DetailUsb 3.0 20pin 19pin
  • ConstructionCopper
  • Converts motherboard 19/20-pin header to USB 3.1 Type E for front-panel connectivity
  • Supports 5 Gbps super-speed transfer, ten times faster than USB 2.0
  • Enables simultaneous two-way data transmission for efficient file moves
  • Shock-resistant copper construction protects signal integrity during handling
  • Includes 0.6 m SATA power cable to supply connected devices

Front-panel USB 3.0 header adapter

This Vszerda adapter converts a motherboard USB 3.0 19/20-pin header into a USB 3.1 Type E header while adding a SATA power cable for devices that need extra current. It targets PC builders who want to connect modern front-panel ports or internal hubs to an older header without rewiring the case. The copper construction is rated shock-resistant for durability inside a chassis. Data runs at up to 5 Gbps with simultaneous two-way transmission.

Upgrading from USB 2.0 front-panel links

The jump is worth it when your case or accessory uses a USB 3.1 Type E connector but the board only offers the legacy 19/20-pin host header. USB 3.0 delivers roughly 10 times the throughput of USB 2.0, so large file transfers to external drives or high-speed card readers finish noticeably faster. The included SATA power lead removes the current limit that often causes port drops on bus-powered hubs. No driver installation is required on any recent Windows or Linux release.

Check header keying and clearance before ordering

Verify that your motherboard header follows the standard 19/20-pin keying; some OEM boards use a proprietary layout that will not mate. Measure the space behind the motherboard tray — the adapter PCB plus the SATA power plug needs enough depth to sit flat without stressing the solder joints. Ensure your power supply has a free SATA connector for the auxiliary lead. This adapter does not add ports; it only changes the header type, so you still need a compatible front-panel device or hub.

Highlights

  • Converts motherboard 19/20-pin header to USB 3.1 Type E for front-panel connectivity
  • Supports 5 Gbps super-speed transfer, ten times faster than USB 2.0
  • Enables simultaneous two-way data transmission for efficient file moves
  • Shock-resistant copper construction protects signal integrity during handling
  • Includes 0.6 m SATA power cable to supply connected devices

Specifications

Brandchenyang
ModelCY-U3-084-EF
TypeUSB 3.0
Connector TypeUsb 3.0 20pin 19pin
Cable Length0.6
Length0.6
Connector DetailUsb 3.0 20pin 19pin
ConstructionCopper
Featuresshock-resistant

Questions about this item

Does the 0.6 m cable reach a front-panel USB 3.1 Type E header from a standard ATX board?

The 0.6 m length is designed for typical front-panel routing in ATX cases; measure your specific board-to-panel distance before buying.

Which way round do the 19-pin and 20-pin plugs go, and do I need the SATA power lead?

Match the keyed 19-pin or 20-pin connector to the motherboard header, then attach the SATA power cable to a drive power connector for stable operation.

Will the copper conductors or shock-resistant jacket degrade if I remove the adapter later?

Copper conductors and the shock-resistant jacket are rated for repeated mating cycles; no scheduled replacement is required under normal use.
