Black steel video wall mount frame with six pop-out VESA bracket arms extending horizontally

VIVO

VIVO 2x3 Pop-Out Video Wall Mount 37-65" 154 lbs per screen

SKU CH-H5TS-A3EFJ

A 2×3 video-wall mount holds six 37-65″ screens up to 154 lb each, with pop-out brackets and micro-leveling adjustments

  • Mount StyleWall
  • TV Size Capacity< 60"
  • WeightMax. load 154 lbs.
  • Holds six 37-65" screens in a 2x3 video wall
  • Pop-out brackets extend 3-8.8" for rear port access
  • Steel rails carry 154 lbs per screen on concrete
  • Micro-adjustments give +3°/-3° swivel and 0 to -1.5° tilt
  • Compatible with VESA patterns from 100x100 to 600x400

2×3 Video Wall Mount for 37–65" Screens

This VIVO wall mount arranges six televisions in a 2-by-3 grid, supporting 37 to 65 inch panels with VESA patterns from 100×100 up to 600×400. Each screen can weigh up to 154 lbs when the rails are fixed to concrete, or 110 lbs when fixed to wood studs. The system is built from black steel and designed for both portrait and landscape orientation.

Pop-Out Brackets and Micro-Adjustments

Push-in pop-out VESA arms extend from 3 to 8.8 inches, giving clear access to rear ports and cabling after the screens are hung. Once mounted, each bracket provides +3° to −3° swivel and 0° to −1.5° tilt, plus horizontal sliding, so all six displays can be levelled and aligned precisely.

Check Wall Structure and VESA Pattern

Verify that your wall can carry the total load — 924 lbs into concrete or 660 lbs into wood studs — and that the mounting points suit the supplied hardware. Confirm each television’s VESA pattern matches one of the listed standards and that its weight does not exceed the per-screen limit for your wall type. The rails measure 160 inches wide, so ensure the installation area accommodates that span.

Highlights

  • Holds six 37-65" screens in a 2x3 video wall
  • Pop-out brackets extend 3-8.8" for rear port access
  • Steel rails carry 154 lbs per screen on concrete
  • Micro-adjustments give +3°/-3° swivel and 0 to -1.5° tilt
  • Compatible with VESA patterns from 100x100 to 600x400

Specifications

Mount StyleWall
TV Size Capacity< 60"
WeightMax. load 154 lbs.

Questions about this item

Will the pop-out VESA brackets need periodic lubrication or replacement after repeated use?

The brackets use fixed steel arms that extend 3 to 8.8 inches; no moving rails or lubrication points are specified, so no scheduled maintenance is required.

What load limit is reached first when six 154-lb screens are mounted on wood studs?

Wood-stud capacity is 110 lbs per screen, so the 660-lb total limit is reached before the 924-lb concrete rating.

How much heat does the steel rail assembly add to a room when all six screens run all day?

The mount is passive steel with no power draw or active components, so it adds no measurable heat beyond the TVs themselves.
