Rectangular beige controller unit with terminal blocks and status LEDs

Viking Electronics

Viking Electronics Two Door Entry Phone Controller

SKU CH-WWFE-BEBMC

Controls two door entry phones with call forwarding and strike relays, ringing up to ten handsets

  • Controls two entry doors with call forwarding and strike relays
  • 120 VAC input with UL-listed 13.8 VAC 1.25 A adapter
  • Operates from 32 °F to 90 °F in 5 % to 95 % humidity
  • SPDT relay rated 5 A at 30 VDC or 125 VAC, 300 VAC max
  • Rings up to ten 0.5 REN phones with 44 VDC talk battery

Two Door Entry Phone Controller

The Viking Electronics Two Door Entry Phone Controller manages access for two separate entry points from a single telephone system. It provides call forwarding so calls can be routed to different numbers or extensions. Integrated door strike controls allow remote unlocking of connected electric strikes or magnetic locks. The unit includes a 120VAC to 13.8VAC 1.25A UL Listed power adapter.

Power and Environmental Requirements

Verify that a 120VAC mains outlet is available at the installation location for the supplied adapter. The controller operates between 32°F and 90°F with humidity from 5% to 95% non-condensing. Ensure the existing telephone wiring can support the 44VDC talk battery and the ring output rated at 5 REN. The SPDT relay contacts are rated for 5A at 30VDC or 125VAC up to 300VAC maximum.

Replaces Separate Single Door Controllers

This unit replaces the need for two individual door phone controllers by combining both entries into one device. The jump is worthwhile when managing dual access points such as front and rear doors or a main gate and lobby entrance. It is not suited for installations requiring more than two door stations or for systems needing IP or network-based access control features.

Highlights

  • Controls two entry doors with call forwarding and strike relays
  • 120 VAC input with UL-listed 13.8 VAC 1.25 A adapter
  • Operates from 32 °F to 90 °F in 5 % to 95 % humidity
  • SPDT relay rated 5 A at 30 VDC or 125 VAC, 300 VAC max
  • Rings up to ten 0.5 REN phones with 44 VDC talk battery

Specifications

No published specifications for this item yet.

Questions about this item

Does the controller ship with the 120VAC / 13.8VAC 1.25A UL Listed Adapter or must I buy it separately?

The package includes the 120VAC / 13.8VAC 1.25A UL Listed Adapter so no separate power supply purchase is required.

Should I select the model rated for 32°F to 90°F operating temperature or is there a wider-range version?

The controller is specified for 32°F to 90°F (0°C to 32°C) with 5% to 95% non-condensing humidity; no alternative temperature range is offered.

What does the 5 REN ring output mean for the number of phones I can connect?

The 5 REN output can ring up to ten 0.5 REN phones simultaneously across the two door entry lines.
