Compact rectangular I/O box with multiple ports and mounting bracket

ViewSonic

ViewSonic VB-IOB-001 Expandable I/O Box install accessory

SKU CH-04YK-XPFYX MPN VB-IOB-001

Adds USB-C, DisplayPort, HDMI, VGA and audio inputs to ViewBoard IFP50-5 series displays via a single HDMI and USB connection

  • FeatureI/O Port - Connect to external device: USB Type-C in: x1, DP
  • HeightPhysical (inch): 204.4 x 38.5 x 23.2 mm Including plate
  • Package Content1. HDMI Cable x1 2.Mounting Bracket x1 3.Screws x2 4.Quick S
  • Expanded connectivity via USB-C, DP 1.2, HDMI 2.0, VGA and 3.5 mm audio inputs
  • USB-powered design removes separate adapters and reduces cable clutter
  • Single HDMI output links all sources to a ViewBoard IFP50-5 series display
  • Compact 204.4 x 38.5 x 23.2 mm form factor fits behind the screen
  • Mounting bracket, screws, HDMI cable and quick-start guide included for immediate setup

Expandable I/O Box for ViewBoard

The ViewSonic VB-IOB-001 adds extra input ports to compatible ViewBoard displays. It is designed for classrooms or meeting rooms that need more connection options for laptops and legacy devices.

Connectors and mounting

The box provides USB Type-C with DisplayPort 1.2 alt mode, DisplayPort 1.2, HDMI 2.0, VGA and 3.5 mm audio inputs. A single HDMI output links to the display, while a USB 2.0 Type-A port passes through touch or data signals. The package includes a mounting bracket, screws and an HDMI cable for a tidy installation behind the screen.

Practical limits

USB Type-C video requires the source to support DisplayPort 1.2 alt mode; plain USB-C data ports will not drive the display. HDMI input is limited to the 2.0 specification, so higher refresh rates or resolutions beyond that standard are not supported. The unit draws power from the ViewBoard USB port, so it cannot operate as a standalone hub without the display.

Highlights

  • Expanded connectivity via USB-C, DP 1.2, HDMI 2.0, VGA and 3.5 mm audio inputs
  • USB-powered design removes separate adapters and reduces cable clutter
  • Single HDMI output links all sources to a ViewBoard IFP50-5 series display
  • Compact 204.4 x 38.5 x 23.2 mm form factor fits behind the screen
  • Mounting bracket, screws, HDMI cable and quick-start guide included for immediate setup

Specifications

BrandViewSonic
FeatureI/O Port - Connect to external device:
USB Type-C in: x1, DP1.2 (Alt mode only)
DP in: x1, DP1.2
HDMI in: x1, HDMI 2.0
VGA in: x1
PC Audio in (3.5mm): x1
I/O Port - Connect to ViewBoard:
HDMI-OUT: x1
USB 2.0 type-A cable: x1
Power Consumption: 5V / 0.5A (by USB port)
OPERATING CONDITIONS:
Temperature (º C): 0? ~ 40?
Humidity: 10% ~ 90% R.H. Non-Condensing
HeightPhysical (inch): 204.4 x 38.5 x 23.2 mm Including plate
Package Content1. HDMI Cable x1
2.Mounting Bracket x1
3.Screws x2
4.Quick Start Guide
Shipping weight0.36 kg
Package size279 × 104 × 41 mm

Questions about this item

What video standard does the DisplayPort 1.2 input support on the VB-IOB-001?

The DisplayPort 1.2 input accepts signals up to the DP 1.2 specification.

What are the physical dimensions including the mounting plate?

The unit measures 204.4 x 38.5 x 23.2 mm with the plate attached.

How is the I/O box powered and what cable is included for the ViewBoard link?

It draws power over USB from the ViewBoard and an HDMI cable is supplied for the HDMI-OUT connection.
