ViewSonic PCE-AX210 PCIe Wi-Fi card with two external antennas

ViewSonic

ViewSonic PCE-AX210 WiFi 6E AX5400 PCIe Wi-Fi adapter

SKU CH-DB8B-B2ENM

Adds tri-band Wi-Fi 6E and Bluetooth 5.3 to a desktop via PCIe x1 with two external antennas

  • ColorWiFi 6E AX210 PCIE Card
  • Wireless Data Rates5400 megabits_per_second
  • Features5400 megabits_per_second
  • Dimensions12.0 in x 8.0 in x 2.0 in
  • Weight0.13 kilograms
  • Tri-band WiFi 6E reaches 5400 Mbps across 2.4, 5 and 6 GHz bands
  • New 6 GHz spectrum adds 7×160 MHz channels for less congestion
  • Bluetooth 5.3 connects peripherals with lower latency and better battery life
  • External 5 dBi antennas plus low-profile bracket suit various chassis sizes
  • Windows 10 and 11 64-bit only; installs via PCIe x1 slot

Desktop Wi-Fi 6E Upgrade

The ViewSonic PCE-AX210 is a PCIe x1 wireless adapter built around the Intel AX210 chipset. It adds tri-band Wi-Fi 6E and Bluetooth 5.3 to a desktop PC running Windows 10 or 11 64-bit. Peak data rates reach 5400 megabits per second across 2.4 GHz, 5 GHz and the new 6 GHz band. The card targets users who need higher throughput and lower latency for 8K streaming, large file transfers or VR applications.

Installation Steps and Common Issues

Fit the card into a free PCIe x1 slot — do not use a x16 slot — then attach the two supplied 5 dBi external antennas and the low-profile bracket if required. Connect the bundled BT USB cable to an internal USB header for Bluetooth 5.3 functionality. Install the driver using the quick installation guide. The adapter will not work on motherboards that contain Intel AC9560 CNVi components and is not compatible with older AMD CPUs, where unknown problems may appear. Some boards also prevent two or more wireless cards from operating simultaneously.

Pre-Purchase Compatibility Checks

Verify that your motherboard has an available PCIe x1 slot and an internal USB header for the Bluetooth cable. Confirm the system runs Windows 10 or 11 64-bit; no other operating systems are supported. Ensure the board does not use an Intel AC9560 CNVi implementation. Check that you are not planning to run a second wireless card in the same machine. Finally, make sure your router supports Wi-Fi 6E and the 6 GHz band to use the full tri-band capability.

Highlights

  • Tri-band WiFi 6E reaches 5400 Mbps across 2.4, 5 and 6 GHz bands
  • New 6 GHz spectrum adds 7×160 MHz channels for less congestion
  • Bluetooth 5.3 connects peripherals with lower latency and better battery life
  • External 5 dBi antennas plus low-profile bracket suit various chassis sizes
  • Windows 10 and 11 64-bit only; installs via PCIe x1 slot

Specifications

BrandViewSonic
ModelPCE-AX210
Part NumberPCE-AX200
ColorWiFi 6E AX210 PCIE Card
Wireless Data Rates5400 megabits_per_second
Features5400 megabits_per_second
Dimensions12.0 in x 8.0 in x 2.0 in
Weight0.13 kilograms

Questions about this item

How do I confirm the ViewSonic PCE-AX210 is working after installation?

After fitting the card into a PCIe x1 slot, attaching the two 5 dBi antennas and connecting the Bluetooth USB cable, install the driver from the Quick Installation Guide; the adapter should then show WiFi 6E networks on the 6 GHz band and pair Bluetooth 5.3 devices in Windows 10 or 11 64-bit.

What comes in the box and what must I buy separately?

The package includes the AX210 PCIe card, two external high-gain antennas, a low-profile bracket, a Bluetooth USB cable and a Quick Installation Guide; no extra cables or brackets are required for a standard desktop install.

Which version of this adapter should I choose for a Windows 11 desktop?

The PCE-AX210 is a single model delivering 5400 Mbps tri-band WiFi 6E (574 Mbps at 2.4 GHz, 2402 Mbps at 5 GHz, 2402 Mbps at 6 GHz) with Bluetooth 5.3 and supports only Windows 10 or 11 64-bit.
