VideoSecu
VideoSecu ML531BE-A14 Full Motion TV Mount 20" Extension 88lbs
Full-motion wall mount tilts, swivels 180° and extends 20" for TVs up to 55" and 88 lbs
- NameTilt Swivel Full Motion TV Wall Mount
- Mount StyleArticulating/Full Motion
- ColorBlack
- MovableTilt +5° / -15º, Swivel up to 180º, Extension 20", Depth 2.2
- TV Size Capacity< 60"
- TV Weight CapacityLoading capacity to 88lbs/40kg
- Supports screens up to 88 lbs for secure mounting
- Extends 20 inches from the wall for flexible positioning
- Swivels up to 180 degrees for wide-angle viewing
- Tilts +5° to -15° to reduce glare and improve comfort
- Folds to 2.2 inches depth for a low-profile look
Full-motion mount for screens up to 55
The VideoSecu ML531BE-A14 is an articulating wall bracket built for flat-panel TVs between 22 and 55 inches. Heavy-duty steel arms support displays weighing up to 88 lbs. It suits living rooms, bedrooms or offices where the viewer wants to pull the screen out, swivel it sideways or tilt it for glare reduction.
VESA pattern and weight limit decide fit
The bracket accepts VESA hole patterns from 100x100 mm through 400x400 mm, covering the four most common square and rectangular layouts. Maximum load is 88 lbs, so any screen heavier than that cannot be mounted safely. Pre-2013 models 42 inches and larger are explicitly excluded regardless of VESA match.
20" extension with 2.2" folded depth
The arm extends a full 20 inches from the wall for corner or deep-sofa viewing, then folds back to a 2.2-inch profile when not in use. Tilt range is +5° to -15° and swivel reaches 180° depending on screen width. Buyers needing more than 20 inches of reach or a higher weight rating should look elsewhere.
Highlights
- Supports screens up to 88 lbs for secure mounting
- Extends 20 inches from the wall for flexible positioning
- Swivels up to 180 degrees for wide-angle viewing
- Tilts +5° to -15° to reduce glare and improve comfort
- Folds to 2.2 inches depth for a low-profile look
Specifications
| Brand | VideoSecu |
|---|---|
| Model | ML531BE-A14 |
| Name | Tilt Swivel Full Motion TV Wall Mount |
| Mount Style | Articulating/Full Motion |
| Color | Black |
| Movable | Tilt +5° / -15º, Swivel up to 180º, Extension 20", Depth 2.2" |
| TV Size Capacity | < 60" |
| TV Weight Capacity | Loading capacity to 88lbs/40kg |
| VESA Compatible | 400x400/ 400x300/ 400x200/ 300x300/ 300x200/ 200x200/ 200x100/ 100x100mm |
| Feature | *Multi-directional adjustment tilt, swivel and extend for perfect viewing angle *Integrated cable management design on articulating arm keeps wire out of the way *Premium quality: constructed with thick, heavy duty durable steel with powder-coated black finish *Post-installation level adjustment allows the TV to perfectly level *Nesting arm design allows display to be folded parallel to the wall to save space *Free 10ft HDMI cable and 6" 3-axis magnetic bubble level *Single stud mounting *Tilt +/- 15º, Swivel up to 180º, Extension 20", Depth 2.2" |
Questions about this item
How far will the 20" extension actually let me pull a 55" screen away from the wall?
The arm extends up to 20 inches from the wall, so a 55 inch TV can be pulled out that full distance for corner or glare-free viewing.
What VESA patterns does the mount accept and what is the largest hole spacing it supports?
It fits VESA patterns from 100x100 mm up to 400x400 mm, covering 100, 200, 300 and 400 mm square and rectangular hole spacings.
How much space does the mount need behind the TV when it is folded flat against the wall?
When folded, the mount sits only 2.2 inches from the wall, so you need at least that depth behind the screen for a low-profile fit.
