Square steel wall plate with tilt hinge, VESA 75/100 holes, silver finish

Vidabox

Vidabox Tilting VESA Wall Mount accessory

SKU CH-T30W-304GT

A tilting VESA 75/100 wall mount with ±10º adjustable tilt, 42.5 mm wall clearance and a locking screw for secure tablet-enclosure mounting

  • Adjustable ±10° tilt for optimal viewing angle
  • VESA 75×75 and 100×100 compatible with wide range of enclosures
  • 5 mm low-profile clearance keeps mount close to wall
  • Locking screw secures tablet enclosure permanently in place
  • Sturdy steel construction with included wall anchors and screws

VESA 75/100 Tilting Wall Mount

This steel wall mount fits VESA 75x75 and 100x100 patterns. It provides adjustable tilt of ±10° for optimal viewing angles. A locking screw secures the attached enclosure permanently. The unit sits 1.67" [42.5mm] from the wall surface.

Pre-Installation Checks

Verify the mounting surface can accept the supplied #12 x 1.5" screws and hollow/solid wall anchors. Ensure the tablet enclosure uses VESA 75 or 100 hole spacing and accepts M4 x 8mm machine screws. Confirm the 4.75" [121mm] square footprint fits the intended wall location.

Build Integration

The two-piece assembly mounts flush to the wall with 1.65" [42mm] depth. It frees up desk or counter space by securing the device vertically. Sturdy steel construction supports the enclosure weight reliably. The package includes all necessary hardware for wall and VESA attachment.

Highlights

  • Adjustable ±10° tilt for optimal viewing angle
  • VESA 75×75 and 100×100 compatible with wide range of enclosures
  • 5 mm low-profile clearance keeps mount close to wall
  • Locking screw secures tablet enclosure permanently in place
  • Sturdy steel construction with included wall anchors and screws

Specifications

No published specifications for this item yet.

Questions about this item

Does the box include everything needed to mount the bracket on a wall and attach a VESA enclosure?

Yes, the package contains the two-piece mount, four wall anchors, four #12 x 1.5" wall screws, four M4 x 8mm machine screws and installation instructions.

Should I choose the VESA 75 or VESA 100 mounting pattern for my enclosure?

The bracket supports both 75 mm and 100 mm square patterns, so use whichever pattern matches the holes on your enclosure.

How far will the mounted enclosure sit from the wall once installed?

The bracket provides 1.67 inches (42.5 mm) of clearance between the wall surface and the back of the enclosure.
