Large blue powder-coated steel platform lift with pneumatic foot pedal, removable ramp sections, central jack

VEVOR

VEVOR JL-M03804 Pneumatic Motorcycle Jack 1500 lbs 7-37 in

SKU CH-M26C-5DZ3F

Pneumatic motorcycle lift raises bikes up to 1500 lbs from 7 to 37 inches with removable three-section ramp and integrated centre jack

  • Width34.25
  • TypeFloor Jacks
  • Vehicle TypeAutomotive
  • Lifts up to 1500 lbs for heavy motorcycles
  • Pneumatic foot-pedal operation reduces manual effort
  • Adjustable height range from 7 to 37 inches
  • Three-piece removable ramp simplifies loading and rear-wheel access
  • Powder-coated steel frame resists corrosion in shop environments

Product Identity

The VEVOR JL-M03804 is a pneumatic motorcycle jack rated for a 1500 lbs weight capacity. It suits professional repair shops and home mechanics who service standard motorcycles, touring bikes, cruisers, ATVs and dirt bikes. The platform measures 78.7 by 48 inches and features a three-section removable ramp for easy loading and rear-wheel access. A built-in center jack adds extra height adjustment for varied service tasks.

Thermals Noise Power

The unit operates on a pneumatic pump driven by compressed air within a 1.6 MPa pressure range. A 300H-3 rubber airbag provides the lifting thrust, delivering smooth and stable elevation without an electric motor. This air-powered design eliminates motor heat and electrical noise during normal use. The powder-coated steel frame and Q235B center jack resist corrosion while supporting the 1100 lbs center-jack load rating.

Sustained Load Behaviour

Under continuous workshop cycles the pneumatic system maintains consistent lifting force through the 7 to 37 inch height range. The airbag's airtightness prevents pressure loss during extended holds at maximum elevation. The 560 lb net weight and broad 112.2 by 51.2 inch footprint keep the platform stable when a 1500 lb motorcycle is raised for long periods. Removable ramp sections and included position pins allow quick reconfiguration between jobs without structural fatigue.

Highlights

  • Lifts up to 1500 lbs for heavy motorcycles
  • Pneumatic foot-pedal operation reduces manual effort
  • Adjustable height range from 7 to 37 inches
  • Three-piece removable ramp simplifies loading and rear-wheel access
  • Powder-coated steel frame resists corrosion in shop environments

Specifications

Width34.25
TypeFloor Jacks
Vehicle TypeAutomotive

Questions about this item

How is the pneumatic motorcycle jack installed and which step is most often missed?

Bolt the frame using the twelve M10*25 screws with washers, spring washers and nuts, plus the four M8 screws and their washers; the step most often missed is inserting the four position pins to lock the ramp sections before use.

What maintenance or replacement will the jack need later?

The rubber 300H-3 airbag operates at 1.6 MPa and should be inspected regularly for cracks or leaks; replace it if the lift becomes unstable or fails to hold the 1500 lbs capacity.

What limit appears first during sustained use?

The centre jack is rated for 1100 lbs, so loading the platform beyond that on the central area will reach its structural limit before the main 1500 lbs pneumatic capacity.
