Silver metal wall-bed hardware kit with two pneumatic rods, left and right mounting brackets and fasteners

VEVOR

VEVOR HW-3701-1200mm-60kg Wall Bed Hardware Kit 154 lbs

SKU CH-J65K-TF1J7

Pneumatic hardware kit supports a vertical wall bed up to 154 lbs with 1200 mm rods and included brackets

  • TypeOther Appliances
  • Width5.12
  • Supports mattress and frame up to 154 lbs total load
  • Pneumatic rods give smooth lift and controlled descent motion
  • Heavy-duty steel brackets and hardware rated for 60 kg capacity
  • Compact 45 mm profile fits tight wall cavities cleanly
  • Includes all M8 screws, nuts and brackets for DIY assembly

154 lbs Wall Bed Hardware Kit

This kit provides the mechanical components required to build a vertical folding wall bed. It supports a combined mattress and frame weight of up to 154 lbs using two pneumatic rods for controlled movement. The hardware is designed for a compatible bed size of 59 by 71 inches. It suits DIY builders creating a guestroom sleeping solution.

Check Wall Structure And Mattress Weight

Verify that the mounting wall can securely anchor the supplied M8x50mm screws and brackets. Weigh the intended mattress and frame together to confirm they do not exceed the 154 lbs capacity. Ensure the room provides enough clearance for the 42.52 by 29.53 inch hardware footprint when the bed is lowered. The kit includes left and right brackets only.

Two Pneumatic Rods Handle Lift And Lower

The pair of pneumatic rods manages the bed weight during daily operation, removing the need for manual springs or counterweights. Included M8 anti-loose and self-locking nuts keep the assembly secure over repeated cycles. The 1.77 inch thick mechanism sits flat against the wall when the bed is stored upright. Floor space is freed entirely when the bed is folded.

Highlights

  • Supports mattress and frame up to 154 lbs total load
  • Pneumatic rods give smooth lift and controlled descent motion
  • Heavy-duty steel brackets and hardware rated for 60 kg capacity
  • Compact 45 mm profile fits tight wall cavities cleanly
  • Includes all M8 screws, nuts and brackets for DIY assembly

Specifications

TypeOther Appliances
Width5.12

Questions about this item

What comes in the HW-3701-1200mm-60kg kit and what must I supply myself?

The kit includes two pneumatic rods, left and right brackets, eight M8x50 mm screws, eight M8 anti-loose nuts and four M8 self-locking nuts. You must provide the bed frame, mattress and any wood or metal panels.

The title mentions 59x71 in compatible bed size and 154 lbs capacity — which figure should I use to choose?

The 154 lbs / 70 kg rating is the maximum load including the mattress, so select this kit only if the combined weight of your frame and mattress stays at or below that limit.

What does the 154 lbs headline figure mean once the wall bed is installed and used daily?

It is the total weight the two pneumatic rods can lift and hold — frame plus mattress — so the assembled bed must not exceed 154 lbs for reliable operation.
