Cast iron V-type three-cylinder air compressor pump head, unpainted metal finish

VEVOR

VEVOR FB-3090/12.5 10HP 17.5CFM 3-Cylinder Air Compressor Pump Head

SKU CH-QDXX-SHKG1

A three-cylinder cast-iron pump head delivers 17.5 CFM at 90 PSI with a 185 PSI maximum

  • TypeOther Appliances
  • Width13.31
  • Delivers 17.5 CFM at 90 PSI for high-demand pneumatic tools
  • Three-cylinder V-type design provides balanced operation and consistent airflow
  • Cast-iron construction withstands continuous duty cycles up to 185 PSI maximum pressure
  • Oil-lubricated pistons reduce wear for extended service life in industrial settings
  • Compact 565 x 420 x 486 mm footprint fits tight workshop spaces

Pump head for 10 HP compressed-air systems

This three-cylinder cast-iron pump head delivers 17.5 CFM at 90 PSI and reaches a maximum pressure of 185 PSI. It is built as a direct replacement for dual-stage V-type compressors requiring that flow and pressure envelope.

Oil-lubricated duty cycle under continuous demand

The oil-lubricated design keeps cylinder walls and bearings protected during extended run periods, allowing the unit to sustain its rated 409 L/min output without the heat-related drop-off seen in splash-lubricated or oil-free heads.

Cast-iron V-block with standard mounting footprint

The V-type cylinder arrangement and 22.2 by 16.5 by 19.1 inch cast-iron housing bolt to common industrial compressor frames, so installation uses existing fasteners and alignment points. At 72.6 lbs the head is heavy enough to damp vibration but still manageable for a two-person lift during change-over.

Highlights

  • Delivers 17.5 CFM at 90 PSI for high-demand pneumatic tools
  • Three-cylinder V-type design provides balanced operation and consistent airflow
  • Cast-iron construction withstands continuous duty cycles up to 185 PSI maximum pressure
  • Oil-lubricated pistons reduce wear for extended service life in industrial settings
  • Compact 565 x 420 x 486 mm footprint fits tight workshop spaces

Specifications

TypeOther Appliances
Width13.31

Questions about this item

How much heat and noise does the 10 HP three-cylinder pump produce when running continuously?

The 10 HP three-cylinder cast-iron pump runs oil-lubricated, which reduces mechanical noise compared with oil-free designs, but sustained 17.5 CFM delivery at 90 PSI will still generate noticeable heat and sound in a workshop.

What separate components must I already own for this pump head to function?

You need a 10 HP electric motor or petrol engine with a matching shaft and pulley, a drive belt, an air receiver tank, pressure switch, safety valve, check valve and plumbing rated for 185 PSI.

Will the FB-3090/12.5 bolt onto my existing two-stage 185 PSI tank and plumbing?

Yes, the V-type dual-stage head is built for 185 PSI systems, so it matches the pressure rating of standard two-stage tanks and fittings; verify bolt pattern and shaft size before fitting.
