Vertiv HMX5150T-DVID KVM switch DVI USB 1920x1200 zero-U
IP KVM transmitter delivers 1920 x 1200 DVI-D video and USB 2.0 keyboard, mouse and touch over RJ45 Ethernet in a zero-U form factor
- TypeDVI, USB
- Console ConnectorsEthernet: 1 x 8p8c (RJ45)
- Computer Connections1 x DVI-D 2 x USB type A
- Video Resolution1920 x 1200
- Power FeaturesUSB power: 2xUSB2.0 (2x 500mA@5V)5W External power: 5VDC, IA
- USB FeaturesUSB: USB2.0 full and low speed (No HS support) USB features:
- Zero-U design saves rack space
- USB power option removes need for external PSU
- Typical draw under 3 W keeps energy use low
- 1920 x 1200 @ 60 Hz over DVI-D
- Integrates with HMX5000/6000 Series infrastructure
Zero-U KVM Transmitter
The Vertiv HMX5150T-DVID is a DVI and USB KVM transmitter designed for server-room deployment. Its zero-U form factor mounts without consuming rack units, targeting administrators who need remote console access over existing IP infrastructure.
Single-Cable Console Link
One RJ45 port carries video, keyboard, mouse and touch data to the HMX5000 or 6000 matrix, while the computer side connects through one DVI-D and two USB type A ports. The unit draws under 3 W typical and can be powered entirely from the USB links, removing the need for a separate power supply in many installations.
Upgrade From Direct-Attach KVM
Replaces local rack-mounted consoles or analogue KVM switches that require dedicated cabling per server. The jump is worthwhile when operators need to manage multiple systems from a single workstation across the network at 1920 x 1200 resolution without adding rack depth.
Highlights
- Zero-U design saves rack space
- USB power option removes need for external PSU
- Typical draw under 3 W keeps energy use low
- 1920 x 1200 @ 60 Hz over DVI-D
- Integrates with HMX5000/6000 Series infrastructure
Specifications
| Brand | Avocent |
|---|---|
| Model | HMX5150T-DVID |
| Type | DVI, USB |
| Console Connectors | Ethernet: 1 x 8p8c (RJ45) |
| Computer Connections | 1 x DVI-D 2 x USB type A |
| Video Resolution | 1920 x 1200 |
| Power Features | USB power: 2xUSB2.0 (2x 500mA@5V)5W External power: 5VDC, IA Typical power consumption: 3W BTU: 10.2BTU/hr |
| USB Features | USB: USB2.0 full and low speed (No HS support) USB features: Keyboard, mouse and touch |
| Features | Zero-U Size The HMX5150T takes zero-U of rack space in the erver room allowing for ultimate flexibility and ease of installation. IP-Based Use your existing networking infrastructure to extend or matrix your computing resources to your users. USB Powered The device can be powered from USB. This means there is no need to provision for an external PSU. Options for powering from an external PSU or redundant PSU are also available. Low Power Consumption Requiring less than 3 Watts, the unit can be powered from USB. This means it could use less than a quarter of the energy when compared t |
| Shipping weight | 0.45 kg |
| Package size | 292 × 245 × 55 mm |
Questions about this item
What video resolution does the DVI-D interface on the HMX5150T-DVID support?
The DVI-D connection supports a maximum resolution of 1920 x 1200 at 60 Hz, delivering full desktop video quality over IP.
What physical space does the zero-U form factor require in a rack?
The zero-U design occupies no rack units, allowing the transmitter to mount vertically or sit on a shelf without consuming any 1U slot.
How is the HMX5150T-DVID powered during installation?
The unit draws under 3 W and can be powered directly from two USB 2.0 ports (2 × 500 mA at 5 V), removing the need for an external power supply in most deployments.
