White CPVC ball valve with lever handle and union connections

Value Brand

Value Brand 3/4" CPVC Ball Valve Union Socket/FNPT 225 psi

SKU CH-0R4M-T2A73

A CPVC ball valve with socket and FNPT connections, rated for 225 psi and temperatures from 32 to 194 degrees Fahrenheit

  • TypeOther
  • Handles up to 225 psi working pressure for demanding plumbing systems
  • Operates reliably from 32 to 194 degrees F across seasonal changes
  • PTFE seats deliver smooth, leak-free sealing over repeated cycles
  • CPVC body resists corrosion and chemical attack in hot-water lines
  • Lever handle allows quick quarter-turn shut-off without tools

CPVC Ball Valve Union

This CPVC ball valve union connects 3/4 inch piping using socket and FNPT ends. It is suited for residential or light commercial plumbing systems that require a full-port shut-off valve. The single-union, two-piece design allows straightforward inline installation and removal for maintenance. Buyers needing larger diameters or flanged connections will need a different fitting.

Installation and Common Issues

The valve installs by solvent-welding the socket ends to CPVC pipe and threading the FNPT ends to matching fittings. Using the correct CPVC primer and cement is essential for leak-free joints. Over-tightening threaded connections can crack the CPVC body. Installers who skip deburring or apply excessive torque often create stress fractures that leak under pressure.

Pressure and Temperature Limits

The valve carries a maximum pressure rating of 225 psi CWP and operates between 32 and 194 degrees F. Exceeding either limit risks seal deformation or body failure. The PTFE seats and EPDM body seals perform within this range but degrade faster near the upper temperature bound. Systems that see pressure spikes or sustained hot water above the rated ceiling require a higher-class valve.

Highlights

  • Handles up to 225 psi working pressure for demanding plumbing systems
  • Operates reliably from 32 to 194 degrees F across seasonal changes
  • PTFE seats deliver smooth, leak-free sealing over repeated cycles
  • CPVC body resists corrosion and chemical attack in hot-water lines
  • Lever handle allows quick quarter-turn shut-off without tools

Specifications

BrandZORO SELECT
TypeOther

Questions about this item

How do I verify the ball valve is sealing correctly after installation?

Pressurise the line up to 225 psi and inspect the socket and FNPT joints for leaks; the lever should move freely between open and closed positions without binding.

What components are included and what must I supply?

The valve body, CPVC ball, PTFE seats, EPDM body seals and CPVC lever handle are supplied; you must provide CPVC pipe, solvent cement, primer and thread sealant for the FNPT connection.

Which version should I choose for a 3/4-inch CPVC system rated to 225 psi?

Select the 3/4-inch socket/FNPT CPVC ball valve with EPDM seals and PTFE seats, rated for 225 psi CWP and a temperature range of 32 to 194 degrees F.
