Polished 316 stainless steel 90° elbow with socket weld ends

Value Brand

Value Brand 1 in 316 Stainless Steel Socket Weld 90° Elbow Class 150

SKU CH-CJ31-58BPF

A 316 stainless steel socket weld elbow redirects flow by 90 degrees in Class 150 piping systems

  • 316 stainless steel resists corrosion in water, oil, gas and steam systems
  • Socket weld female ends create a secure 90-degree directional change for 1-inch pipe
  • Class 150 pressure rating meets ASTM A351, ANSI B16.5 and MSS SP-51 standards
  • 11 threads per inch on both connections ensure compatible fit with matching components
  • Suitable for potable and non-potable water, air, natural gas, oil and steam applications

1-inch 316 stainless socket-weld elbow

This 90-degree elbow connects two pipes at a right angle using socket-weld female ends sized for 1-inch nominal diameter. It is constructed from 316 stainless steel for corrosion resistance and rated Class 150 for pressure service. The fitting meets ASTM-A-351, ANSI B16.5 and MSS-SP-51 standards for material, dimensions and temperature ratings. Suitable for air, natural gas, non-potable water, oil, potable water and steam systems.

No bundled accessories or software included

The product is supplied as a single fitting without additional components, sealants or documentation beyond the manufacturer specifications. Thread pitch is 11 threads per inch on both socket ends and no pre-applied thread sealant is present. Installation will require compatible pipe, welding equipment and appropriate joint preparation per the applicable piping code. The fitting itself does not alter system design requirements.

Verify nominal size, pressure class

Confirm that the 1-inch nominal pipe size matches the piping schedule and outer diameter of your existing system. Ensure the Class 150 pressure rating satisfies the maximum operating pressure and temperature of the intended service. Check that 316 stainless steel is compatible with the specific fluid chemistry and that socket-weld joining is permitted by the relevant piping specification for your application.

Highlights

  • 316 stainless steel resists corrosion in water, oil, gas and steam systems
  • Socket weld female ends create a secure 90-degree directional change for 1-inch pipe
  • Class 150 pressure rating meets ASTM A351, ANSI B16.5 and MSS SP-51 standards
  • 11 threads per inch on both connections ensure compatible fit with matching components
  • Suitable for potable and non-potable water, air, natural gas, oil and steam applications

Specifications

BrandZoro Select

Questions about this item

Will the 316 stainless steel 90-degree elbow need periodic replacement due to corrosion?

The 316 stainless steel construction provides corrosion resistance for the listed fluids; under normal conditions within its Class 150 rating it is not a scheduled maintenance item.

What pressure limit governs sustained operation of this Class 150 socket weld elbow?

The fitting meets ASTM A351, ANSI B16.5 and MSS SP-51 Class 150 standards, so the Class 150 pressure-temperature rating is the governing limit for continuous service.

Does the socket weld elbow generate noise, heat or power draw during all-day fluid flow?

As a passive 316 stainless steel fitting with no moving parts or electrical components, it produces no noise, no heat beyond the fluid temperature and draws no power.
